C95400 General Aluminum Bronze Bushing Higher Mechanical Performance Param

Brand Name:	viiplus Aluminum bronze bearing bush
Model Number:	Aluminum bronze bearing bush
MOQ:	negotiate
Price:	negotiate
Payment Terms:	MoneyGram, Western Union, T/T
Supply Ability:	1000000 Piece/Pieces One week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ASTM B505 B505M-2018

Material:

C95400 ASTM B505 B505M-2018

Feature:

High Wear Resistance, High Strength

Application Field:

Furniture, Trains, Ships, Airplanes And Fitness Equipment

Bearing Bushing Factory Price:

Tiffany@viiplus.com

Self-lubricating Bearing Bushing Manufacturer:

Https://www.viiplus.com/

High Light::

Self-Lubricating Sintered Bronze Bushing

Characteristic:

Bronze Bushings With Grease Reservoirs ( BRO-MET, FB090, BRM10, WB800)

Bush Bearings Manufacturers Suppliers Exporters:

Plain Bearings. Long, Maintenance-free Service, Manufactures Bushings In Various Designs And From Different Materials. Tiffany@viiplus.com, Bushings - Configure And Purchase - Https://www.viiplus.com/

Packaging Details:

Export Carton Wood Pallet Wooden Case

Supply Ability:

1000000 Piece/Pieces One week

Highlight:

oil embedded sleeve bearing

graphite sleeve bearings

Product Description

The C95400 General Aluminum Bronze Bushing exhibits higher mechanical performance parameters, making it a superior choice for various industrial applications. Constructed from aluminum bronze, this bushing offers excellent wear resistance, corrosion resistance, and strength, ensuring longer service life and reliable operation. The higher mechanical performance parameters of C95400 aluminum bronze ensure that the bushing can withstand high loads and stresses, maintaining its integrity and functionality under extreme conditions. Wh used in machinery, equipment, or any other demanding industrial setting, the C95400 General Aluminum Bronze Bushing is a dependable component that delivers exceptional performance.

C95400 aluminum bronze bearing sleeve, copper alloy bearing sleeve performance, wear resistance to the leading

C95400 aluminum bronze bearing sleeve is a high-wear bearing, made of a new type of material, with good mechanical properties, high strength, high hardness, good elongation, and does not contain lead, is an environmental protection material, is currently replacing some traditional tin bronze bearings, will be the mainstream bronze bearing leader in the future

Material composition of C95400 aluminum bronze bearing sleeve

CuAl11Fe4=C95400(ASTM B505 B505M-2018)Chemical composition quality/%
Cu	Sn	Al	Fe	Mn	Ni	Pb	Si	P	Zn
Min83.0	-	10.5-11.5	3.0-5.0	0.5	1.5	-	-	-	-

Mechanical properties of C95400 Bronze bearing bush materials

Tensile strength(Mpa)	Yield strength(Mpa)	Ductility%	Hardness (HB)
586	221	12	170

Aluminum bronze, aluminum bronze tube has good cutting and grinding performance, can be welded, easy to form hot machining.Aluminum bronze, aluminum bronze tube is mainly used for manufacturing.

C95400 General Aluminum Bronze Bushing Higher Mechanical Performance Param 0

C95400 Bronze Self lubricating bearing bush Lubrication principle

C95400 General Aluminum Bronze Bushing Higher Mechanical Performance Param 1

Note: since there is oil groove or no oil groove in the C95400 bronze bearing,

please select the appropriate bearing lubricating grease or the lubricating oil to achieve the best self-lubricating effect according to the speed, operating temperature, noise reduction, water resistance and load of the bearing.

You can also choose the C95400 bronze bearing grooved type or not grooved

C95400 General Aluminum Bronze Bushing Higher Mechanical Performance Param 2

You can also choose the C95400 bronze bearing structure

C95400 General Aluminum Bronze Bushing Higher Mechanical Performance Param 3

let's know a little bit about our bushing production process

C95400 General Aluminum Bronze Bushing Higher Mechanical Performance Param 4

The following table shows you can choose some sizes of C95400 bronze bearing sleeve. If you want to know more sizes, please contact me

inner diameter		Outer diameter		L -0.1 -0.3
d		D		20	30	35	40	50	60	70	80
50	+0.050 +0.025	60	+0.030 +0.011	506020	506030	506035	506040	506050	506060	506070	506080
"	"	62	"		506230	506235	506240	506250	506260	506270	506280
"	"	65	"		506530		506540	506550	506560	506570	506580
55	+0.060 +0.030	70	"		557030	557035	557040	557050	557060	557070
60	"	74	"		607430	607435	607440	607450	607460	607470	607480
"	"	75	"		607530	607535	607540	607550	607560	607570	607580
63	"	"	"						637560	637570	637580
65	"	80	"				658040	658050	658060	658070	658080
70	"	85	+0.035 +0.013		708530	708535	708540	708550	708560	708570	708580
"	"	90	"					709050	709060	709070	709080
75	"	"	"					759050	759060	759070	759080
"	"	95	"						759560	759570	759580
80	"	96	"				809640	809650	809660	809670	809680
"	"	100	"				8010040	8010050	8010060	8010070	8010080

We can also assist you to design the C95400 bearing, slider, washer and other parts you need

C95400 General Aluminum Bronze Bushing Higher Mechanical Performance Param 5

Please contact me for more information
