Large Selection of Plain Bushings Materials and Dimensions, High Quality, Customized, high-strength fiber
| Place of Origin | MADE IN CHINA |
|---|---|
| Brand Name | VIIPLUS PLAIN BEARINGS |
| Certification | CUSN8,CUSN6.5 Bronze |
| Model Number | PTFE PLAIN BEARINGS |
| Minimum Order Quantity | 1000 Piece/Pieces (Min. Order) |
| Price | $0.20 - $10.00 / Pieces |
| Packaging Details | Wooden pallets for standard export packing cartons |
| Delivery Time | 10~15 work days |
| Payment Terms | T/T PREPARD, T/T, L/C, D/A, D/P |
| Supply Ability | 2000000 Piece/Pieces |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | EPB A Thermal Mould Character Plastic | Application | Packaging Machinery |
|---|---|---|---|
| Type | Self-lubricating Bearings | Service | OEM Customized Services |
| Product Name | Plastic Plain Bearings Bushing | Stock | Fully Stocked |
| Bearing Bushing Factory Price | Tiffany@viiplus.com | Self-lubricating Bearing Bushing Manufacturer | Https://www.viiplus.com/ |
| Bush Bearings Manufacturers Suppliers Exporters | Plain Bearings. Long, Maintenance-free Service, Manufactures Bushings In Various Designs And From Different Materials. Tiffany@viiplus.com, Bushings - Configure And Purchase - Https://www.viiplus.com/ | ||
| High Light | plastic flanged sleeve bearings,igus plastic bushings |
||
Product Description
Maintenance-free plastic sliding bushings & bearings. Online- shop with large selection of bearing materials and dimensions.
Plastic Bearings & bushings Industry solutions | Plain Flanged bearing
EP plastic bearings and traditional oil bearing replace IGUS bushings plain bushings self-lubricating bearings
Plastic Compound Bearings Plain Bearings Metric Cylindrical Bushes EPB Sliding Bearings Black Lubricating Bushes
Plastic Bushing Characteristics
● A special material for the application in water. The wear resistance could even be improved in water. It is able to be continously operated in a chemical liquid with temperature of 200 ℃
● Continuous working temperature: -40℃/+200℃
● Good wear resistance under high load
● Suitable for underwater operation
● Good chemical resistance
Plastic Bushing Material property sheet
|
Common Capability |
Unit |
EPT |
EPG |
EPH |
EPX |
EPJ |
EPS |
|
Density |
g/cm³ |
1.46 |
1.46 |
1.65 |
|
1.49 |
1.24 |
|
Color |
|
Black gray |
Dark grey |
Grey |
Black |
Yellow |
Beige |
|
Max.water absorption,23℃/ 50% |
[% weight] |
0.2 |
0.7 |
0.1 |
|
0.3 |
2.02 |
|
Max.water absorption |
[% weight] |
＜1.2 |
＜4 |
＜0.3 |
＜0.5 |
＜1.3 |
＜0.1 |
|
Dynamic friction /steel |
μ |
0.05-0.15 |
0.08-0.18 |
0.07-0.20 |
0.09-0.27 |
0.06-0.18 |
0.05-0.15 |
|
Max.PV(dry) |
MPa•m/s |
0.4 |
0.5 |
1.37 |
1.32 |
0.34 |
0.4 |
|
Mechanical behavior |
|||||||
|
E-module |
MPa |
2,300 |
7,800 |
12,500 |
8,100 |
2,400 |
830 |
|
Tensile strength,20℃ |
MPa |
80 |
200 |
175 |
170 |
73 |
18 |
|
Compressive strength |
MPa |
65 |
80 |
90 |
150 |
35 |
10 |
|
Max.static pressure of the surface,20℃ |
MPa |
35 |
80 |
150 |
90 |
20 |
10 |
|
Shore D hardness |
|
70 |
112 |
87 |
85 |
74 |
73 |
|
Physical and thermal properties |
|||||||
|
Continuous work tempreature |
℃ |
+80 |
+130 |
+200 |
+250 |
+90 |
+260 |
|
short-time work tempreature |
℃ |
+120 |
+220 |
+240 |
+315 |
+120 |
+310 |
|
Minimum operating temperature |
℃ |
-40 |
-40 |
-40 |
-100 |
-50 |
-200 |
|
Thermal conductivity |
W/m•K |
0.2 |
0.25 |
0.60 |
0.60 |
0.25 |
0.24 |
|
Max.water absorption,23℃ |
K-1•10-5 |
7 |
9 |
4 |
5 |
10 |
12 |
|
Conductivity |
|||||||
|
Volume resisticity |
Ωcm |
＞1012 |
＞1013 |
＜104 |
＜105 |
＞1013 |
＞1015 |
|
Surface resisticity |
Ω |
＞1015 |
＞1011 |
＜105 |
＜103 |
＞1012 |
＞1015 |
Plastic Bushing Characteristics
EP series of materials has excellent self-lubricating and wear resistance is mainly engineers take full advantage of the self-lubricating material modification technology, high-performance engineering plastics used in high-strength fiber to improve the material load and special grease reduced The friction coefficient of the material (Figure 1), thereby enhancing the comprehensive wear resistance of the material to extend the service life of the bearing. High-performance engineering plastics as the base material mainly as wear-resistant carrier; Reinforced fiber to improve the bearing in the bearing and impact resistance; Special grease reduces the coefficient of friction of the bearing from the role of lubrication.
Typical Applications
·Office Machinery
·Electronic Products
·Textile Machinery
·Fitness Machinery
·Agricultural Machinery
·Packaging Machinery
·Automotive Industry
Solid-lubricating and Maintenancefree Sliding Bearings
Plastic bearing has longe service vs Metal bearing lubricating oil is life easy to be failed
Engineers are dedicated on the performance improvement on the self- lubricating materials derives the result that EP Series Materials are with excellent self- lubricating features and wear resistance Features. High- strength fibers used in the engineering plastics fantastically improve the material load (Graphl). Special grease immersion in the plastic can decrease the friction coefficient of the material therefore to proiong the bearing sevice life. High-performance engineering plastics body material mainly service as wear- resistant vector. The reinfoced fiber improves the load and impact resistant capacity of the beaing. Special grease decreases the fiction coefficient for a better selflubricating performance.
OILES Multi Layered Bearings refer to plain bearings of thin walled with self-lubricating functions.
They are high performance, high quality, lubrication-free and maintenance-free bearings for various industries.
EP PALSTIC BUSHING Series Specification Table
Metric Cylindrical Bushes
| Size and Specification table of straight sleeve series (for all sizes of different materials) | ||||
| model | d | tolerance | D | L |
| EP PLASTIC BUSHING-0304-03 | 3 | +0.014/+0.054 | 4.5 | 3 |
| EP PLASTIC BUSHING-0304-06 | 3 | +0.014/+0.054 | 4.5 | 6 |
| EP PLASTIC BUSHING-0305-05 | 3 | +0.014/+0.054 | 5.5 | 5 |
| EP PLASTIC BUSHING-0405-06 | 4 | +0.020/+0.068 | 5.5 | 6 |
| EP PLASTIC BUSHING-0406-06 | 4 | +0.020/+0.068 | 6 | 6 |
| EP PLASTIC BUSHING-0507-05 | 5 | +0.020/+0.068 | 7 | 5 |
| EP PLASTIC BUSHING-0507-08 | 5 | +0.020/+0.068 | 7 | 8 |
| EP PLASTIC BUSHING-0507-10 | 5 | +0.020/+0.068 | 7 | 10 |
| EP PLASTIC BUSHING-0507-18 | 5 | +0.020/+0.068 | 7 | 18 |
| EP PLASTIC BUSHING-0608-04 | 6 | +0.020/+0.068 | 8 | 4 |
| EP PLASTIC BUSHING-0608-06 | 6 | +0.020/+0.068 | 8 | 6 |
| EP PLASTIC BUSHING-0608-08 | 6 | +0.020/+0.068 | 8 | 8 |
| EP PLASTIC BUSHING-0608-10 | 6 | +0.020/+0.068 | 8 | 10 |
| EP PLASTIC BUSHING-0608-11 | 6 | +0.020/4-0.068 | 8 | 11 |
| EP PLASTIC BUSHING-0810-05 | 8 | +0.025/+0.083 | 10 | 5 |
| EP PLASTIC BUSHING-0810-06 | 8 | +0.025/4-0.083 | 10 | 6 |
| EP PLASTIC BUSHING-0810-08 | 8 | +0.025/+0.083 | 10 | 8 |
| EP PLASTIC BUSHING-0810-10 | 8 | +0.025/4-0.083 | 10 | 10 |
| EP PLASTIC BUSHING-0810-11 | 8 | +0.025/+0.083 | 10 | 11 |
| EP PLASTIC BUSHING-0810-12 | 8 | +0.025/+0.083 | 10 | 12 |
| EP PLASTIC BUSHING-0810-15 | 8 | +0.025/+0.083 | 10 | 15 |
| EP PLASTIC BUSHING-0811-10 | 8 | +0.025/+0.083 | 11 | 10 |
| EP PLASTIC BUSHING-0812-10 | 8 | +0.025/+0.083 | 12 | 10 |
| EP PLASTIC BUSHING-0911-06 | 9 | +0.025/4-0.083 | 11 | 6 |
| EP PLASTIC BUSHING-1012-04 | 10 | +0.025/+0.083 | 12 | 4 |
| EP PLASTIC BUSHING-1012-05 | 10 | +0.025/+0.083 | 12 | 5 |
| EP PLASTIC BUSHING-1012-06 | 10 | +0.025/+0.083 | 12 | 6 |
| EP PLASTIC BUSHING-1012-08 | 10 | +0.025/+0.083 | 12 | 8 |
| EP PLASTIC BUSHING-1012-10 | 10 | +0.025/+0.083 | 12 | 10 |
| EP PLASTIC BUSHING-1012-12 | 10 | +0.025/+0.083 | 12 | 12 |
| EP PLASTIC BUSHING-1012-15 | 10 | +0.025/+0.083 | 12 | 15 |
| EP PLASTIC BUSHING-1014-10 | 10 | +0.013/+0.071 | 14 | 10 |
| EP PLASTIC BUSHING-1014-16 | 10 | +0.025/+0.083 | 14 | 16 |
| EP PLASTIC BUSHING-1012-18 | 10 | +0.025/+0.083 | 12 | 18 |
| EP PLASTIC BUSHING-1012-20 | 10 | +0.025/+0.083 | 12 | 20 |
| EP PLASTIC BUSHING-1214-06 | 12 | +0.032/+0.102 | 14 | 6 |
| EP PLASTIC BUSHING-1214-08 | 12 | +0.032/+0.102 | 14 | 8 |
| EP PLASTIC BUSHING-1214-10 | 12 | +0.032/+0.102 | 14 | 10 |
| EP PLASTIC BUSHING-1214-12 | 12 | +0.032/+0.102 | 14 | 12 |
| EP PLASTIC BUSHING-1214-15 | 12 | +0.032/+0.102 | 14 | 15 |
| EP PLASTIC BUSHING-1214-20 | 12 | +0.032/+0.102 | 14 | 20 |
| Size and Specification table of straight sleeve series (for all sizes of different materials) | ||||
| model | id | tolerance | D | L |
| EP PLASTIC BUSHING-1820-20 | 18 | +0.032/+0.102 | 20 | 20 |
| EP PLASTIC BUSHING-1820-25 | 18 | +0.032/+0.102 | 20 | 25 |
| EP PLASTIC BUSHING-2022-12 | 20 | +0.040/+0.124 | 22 | 12 |
| EP PLASTIC BUSHING-2022-15 | 20 | +0.040/+0.124 | 22 | 15 |
| EP PLASTIC BUSHING-2022-28 | 20 | +0.040/+0.124 | 22 | 28 |
| EP PLASTIC BUSHING-2023-10 | 20 | +0.040/+0.124 | 23 | 10 |
| EP PLASTIC BUSHING-2023-15 | 20 | +0.040/+0J24 | 23 | 15 |
| EP PLASTIC BUSHING-2023-20 | 20 | +0.040/+0.124 | 23 | 20 |
| EP PLASTIC BUSHING-2023-23 | 20 | +0.040/+0.124 | 23 | 23 |
| EP PLASTIC BUSHING-2023-25 | 20 | +0.040/+0.124 | 23 | 25 |
| EP PLASTIC BUSHING-2023-30 | 20 | +0.040/+0.124 | 23 | 30 |
| EP PLASTIC BUSHING-2025-15S | 20 | +0.020/+0.104 | 25 | 15 |
| EP PLASTIC BUSHING-2125-32 | 21 | +0.040/+0.124 | 25 | 32 |
| EP PLASTIC BUSHING-2225-15 | 22 | +0.040/+0.124 | 25 | 15 |
| EP PLASTIC BUSHING-2225-20 | 22 | +0.040/+0.124 | 25 | 20 |
| EP PLASTIC BUSHING-2225-25 | 22 | +0.040/+0.124 | 25 | 25 |
| EP PLASTIC BUSHING-2225-30 | 22 | +0.040/+0J24 | 25 | 30 |
| EP PLASTIC BUSHING-2528-10 | 25 | +0.040/+0.124 | 28 | 10 |
| EP PLASTIC BUSHING-2528-12 | 25 | +0.040/+0.124 | 28 | 12 |
| EP PLASTIC BUSHING-2528-15 | 25 | +0.040/+0.124 | 28 | 15 |
| EP PLASTIC BUSHING-2528-20 | 25 | +0.040/+0.124 | 28 | 20 |
| EP PLASTIC BUSHING-2528-25 | 25 | +0.040/+0.124 | 28 | 25 |
| EP PLASTIC BUSHING-2528-30 | 25 | +0.040/+0.124 | 28 | 30 |
| EP PLASTIC BUSHING-2529-25 | 25 | +0.040/+0.124 | 29 | 25 |
| EP PLASTIC BUSHING-2530-25S | 25 | +0.020/+0.104 | 30 | 25 |
| EP PLASTIC BUSHING-2832-20 | 28 | +0.040/+0.124 | 32 | 20 |
| EP PLASTIC BUSHING-2832-25 | 28 | +0.040/+0J24 | 32 | 25 |
| EP PLASTIC BUSHING-2832-30 | 28 | +0.040/+0.124 | 32 | 30 |
| EP PLASTIC BUSHING-3034-20 | 30 | +0.040/+0.124 | 34 | 20 |
| EP PLASTIC BUSHING-3034-25 | 30 | +0.040/+0.124 | 34 | 25 |
| EP PLASTIC BUSHING-3034-30 | 30 | +0.040/+0.124 | 34 | 30 |
| EP PLASTIC BUSHING-3034-40 | 32 | +0.040/+0.124 | 34 | 40 |
| EP PLASTIC BUSHING 3236-20 | 32 | +0.050/+0.150 | 36 | 20 |
| EP PLASTIC BUSHING-3236-23 | 32 | +0.050/+0.150 | 36 | 23 |
| EP PLASTIC BUSHING-3236-25 | 32 | +0.050/+0.150 | 36 | 25 |
| EP PLASTIC BUSHING-3236-30 | 32 | +0.050/+0.150 | 36 | 30 |
| EP PLASTIC BUSHING-3236-40 | 32 | +0.050/+0J50 | 36 | 40 |
| EP PLASTIC BUSHING-3539-15 | 35 | +0.050/+0.150 | 39 | 15 |
| EP PLASTIC BUSHING-3539-20 | 35 | +0.050/+0.150 | 39 | 20 |
| EP PLASTIC BUSHING-3539-25 | 35 | +0.050/+0.150 | 39 | 25 |
| EP PLASTIC BUSHING-3539-30 | 35 | +0.050/+0.150 | 39 | 30 |
SELF-LUBRICATING BEARING
| Size and Specification table of straight sleeve series (for all sizes of different materials) | ||||
| EP PLASTIC BUSHING-1214-25 | 12 | +0.032/+0.102 | 14 | 25 |
| EP PLASTIC BUSHING-1215-20 | 12 | +0.032/+0.102 | 15 | 20 |
| EP PLASTIC BUSHING-1315-07 | 13 | +0.032/+0.102 | 15 | 7 |
| EP PLASTIC BUSHING-1315-10 | 13 | +0.032/+0.102 | 15 | 10 |
| EP PLASTIC BUSHING-1416-08 | 14 | +0.032/+0.102 | 16 | 8 |
| EP PLASTIC BUSHING-1416-10 | 14 | +0.032/+0.102 | 16 | 10 |
| EP PLASTIC BUSHING-1416-15 | 14 | +0.032/+0.102 | 16 | 15 |
| EP PLASTIC BUSHING-1416-20 | 14 | +0.032/+0.102 | 16 | 20 |
| EP PLASTIC BUSHING-1416-25 | 14 | +0.032/+0.102 | 16 | 25 |
| EP PLASTIC BUSHING-1517-10 | 15 | +0.032/+0.102 | 17 | 10 |
| EP PLASTIC BUSHING-1517-15 | 15 | +0.032/+0.102 | 17 | 15 |
| EP PLASTIC BUSHING-1517-17 | 15 | +0.032/+0.102 | 17 | 17 |
| EP PLASTIC BUSHING-1517-20 | 15 | +0.032/+0.102 | 17 | 20 |
| EP PLASTIC BUSHING-1517-25 | 15 | +0.032/+0.102 | 17 | 25 |
| EP PLASTIC BUSHING-1618-10 | 16 | +0.032/+0.102 | 18 | 10 |
| EP PLASTIC BUSHING-1618-12 | 16 | +0.032/+0.102 | 18 | 12 |
| EP PLASTIC BUSHING-1618-15 | 16 | +0.032/+0.102 | 18 | 15 |
| EP PLASTIC BUSHING-1618-20 | 16 | +0.032/+0.102 | 18 | 20 |
| EP PLASTIC BUSHING-1616-25 | 16 | +0.032/+0.102 | 18 | 25 |
| EP PLASTIC BUSHING-1620-16S | 16 | +0.016/+0.086 | 20 | 16 |
| EP PLASTIC BUSHING-1820-15 | 18 | +0.032/+0.102 | 20 | 15 |
| Size and Specification table of straight sleeve series (for all sizes of different materials) | ||||
| EP PLASTIC BUSHING-3539-40 | 35 | +0.050/+0.150 | 39 | 40 |
| EP PLASTIC BUSHING-359-50 | 35 | +0.050/+0.150 | 39 | 50 |
| EP PLASTIC BUSHING-4044-20 | 40 | +0.050/+0.150 | 44 | 20 |
| EP PLASTIC BUSHING-4044-30 | 40 | +0.050/+0.150 | 44 | 30 |
| EP PLASTIC BUSHING-4044-40 | 40 | +0.050/+0.150 | 44 | 40 |
| EP PLASTIC BUSHING-4044-50 | 40 | +0.050/+0.150 | 44 | 50 |
| EP PLASTIC BUSHING-4550-30 | 45 | +0.050/+0.150 | 50 | 30 |
| EP PLASTIC BUSHING-4550-40 | 45 | +0.025/+0.125 | 50 | 40 |
| EP PLASTIC BUSHING-4550-50 | 45 | +0.050/+0.150 | 50 | 50 |
| EP PLASTIC BUSHING-5055-20 | 50 | +0.050/+0.150 | 55 | 20 |
| EP PLASTIC BUSHING-5055-30 | 50 | +0.050/+0.150 | 55 | 30 |
| EP PLASTIC BUSHING-5055-40 | 50 | +0.050/+0.150 | 55 | 40 |
| EP PLASTIC BUSHING-5055-50 | 50 | +0.050/+0.150 | 55 | 50 |
| EP PLASTIC BUSHING-8590-40 | 85 | +0.036/+0.176 | 90 | 40 |
•Tolerance drafter being pressed into housing H7(ISO3547-1)
Recommend fitting tolerance
Housing: H7
Shaft: H9
Plastic Bushing Types
-
Cylindrical Bushings
-
Flanged Bushings
-
Thrust Washer
-
Thrust Plate
-
Plate for Machining
-
Other Bushings & Self-Lubricating Bearings
Recommended Products
