Garlock Bearing Metal - Polymer Plain Bearings | Cylindrical Thrust Bushing Tin / Copper Plating
| Place of Origin | MADE IN CHINA |
|---|---|
| Brand Name | VIIPLUS PLAIN BEARINGS |
| Certification | CUSN8,CUSN6.5 Bronze |
| Model Number | PTFE PLAIN BEARINGS |
| Minimum Order Quantity | 1000 Piece/Pieces (Min. Order) |
| Price | $0.20 - $10.00 / Pieces |
| Packaging Details | Wooden pallets for standard export packing cartons |
| Delivery Time | 10~15 work days |
| Payment Terms | T/T PREPARD, T/T, L/C, D/A, D/P |
| Supply Ability | 2000000 Piece/Pieces |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Meterial | Carton Steel , Bronze , PTFE | Plating | Tin Or Copper |
|---|---|---|---|
| Characteristic | Low-maintenance And Maintenance-free Plain Bearings | Type | Bushes, Collar Bushes, Washers, Strips Or Special Designs |
| Size | Standard Size Available,OEM | Port | Shanghai |
| Bearing Bushing Factory Price | Tiffany@viiplus.com | Self-lubricating Bearing Bushing Manufacturer | Https://www.viiplus.com/ |
| Bush Bearings Manufacturers Suppliers Exporters | Plain Bearings. Long, Maintenance-free Service, Manufactures Bushings In Various Designs And From Different Materials. Tiffany@viiplus.com, Bushings - Configure And Purchase - Https://www.viiplus.com/ | ||
| High Light | plastic flanged sleeve bearings,igus plastic bushings |
||
Product Description
Plastic plain bearing
VIIPLUS Dry Sliding Bearings manufactures a complete range of Bushing Bearings and Cast Bronze Bearings Materials all of which are made to the highest standards to optimize your products performance.Hardened Steel Bushings Plain Sleeve Bearing Garlock Bearing Die & Mold Bushes
Metal-Polymer Anti-Friction hydraulic pumps steel bronze bushing Plain Bearings self-lubricating Bearings Cylindrical PTFE Concrete Pumps steel bushing | VSB-10
The Self-Lubrciating Bearings of Technology,a range of Plain BearingS products that has gained an excellent reputation for reliability and performance.
.As China Manufacturer in the field of Steel Ptfe Sleeve Bushing technology, VIIPLUS Oilless BEARINGS supplies
.As China Manufacturer in the field of Steel Ptfe Sleeve Bushing technology, VIIPLUS Oilless BEARINGS supplies
Flanged Bushing Carbon Steel/Stainless Seel PTFE Bush
DU bushing model MB5020-65FDU
tri-layer maintanence-free bushing have a base of lower carbon steel, onto which a porous bronze layer is sintered. PTFE mixtures are impregnated into the intersice of this bronze layer after rolling process completed. it has good physical & mechanical properties, also has certainly chemical properties. It is suitable for rotary, oscillating movement with performance of self-lub. Anti-wear, lower firction, lower noise.
1. Self-lubraiting Layer PTFE Mixture 0.01-0.03mm. After rolling process completed, PTFE mixtures are filled in intersice of bronze layer. Under normal operation, Part of PTFE mixture on top layer will be removed and transferred on the mating surface, forms a physically lubricating film, which will reduced the firction. and protect the mating shaft.
2. Porous Bronze layer; The layer provides bonded strength of Self-Lubricating Layer.
3. Steel Backing The layer provides load & thermal conductivity
4. Copper / Tin layer
2. Porous Bronze layer; The layer provides bonded strength of Self-Lubricating Layer.
3. Steel Backing The layer provides load & thermal conductivity
4. Copper / Tin layer
PTFE material slide bearing DU dry bushing factory ,Bronze copper plating steel backing DX POM Bush china manufacturer
Metal-Polymer Anti-Friction Plain Bearings
- composite
- plain bearings
- Compact and maintenance-free
- ROLLED DRY SLIDING BEARINGS (PTFE)
- Steel + Bronze Powder + PTFE/Fibre(DU)
- Wrapped PTFE Lined (maintenance-free), self lubricated plain or flanged bearings, thrust washer and strip, Carbon steel shell with sintered bronze layer filled with PTFE
Typical Applications
Hydraulic industry
Gear pump, water pump, piston pump, ball valve, butterfly valve, valve, control valve, reciprocating air compressor, hydraulic brake, centrifugal compressor, hydraulic cylinder, etc..
Characteristics
VSB-10 Self-Lubricating Multilayer Composite Bushing
- Bushing material suitable for lubricated applications
- self-lubricating bushings offer very good wear and low friction performance over a wide range of loads, speeds and temperatures in dry running conditions
- Anti-friction bearing suitable for linear, oscillating and rotating movements
- Material is designed to operate without supplemental lubrication and will perform excellent when lubrication is present. Low friction, low wear rate, good sliding characteristics and very low absorption are a few of the features of this material. VSB-10 bushings will support rotary, linear and oscillating motion.
Strusture
1. PTFE/Fibre mixture thickness 0.01~0.03mm. It is the contact surface for the rotating shaft. Minute partides of the PTFE layer and the sintered bronze material combine to create a solid lubricant film, which coats the shaft.
2. Sintered bronze powder thickness 0.20*0.35mm,A special composition of powdered copper is thermally fused to the steel backing. This contact layer acts as an anchor for the PTFE layer and conducts the thermal build up away from the bearing surfaces.
3. Low-carbon steel backing. Setting the foundation of the bushings, the steel back provides exceptional stability, load carrying and heat dissipation characteristics.
Technical Data
Carbon Steel + Copper Powder + (PTFE + Pb + Filler)
Structure And Composition
· Metal-Polymer Composite Self-lubricating Bushing Material
· Steel Back + Porous Bronze Sinter +
· PTFE + Lead
Microsection
|
Sliding layer |
| OPERATING PERFORMANCE | |
| Dry | Very Good |
| Oil lubricated | Good |
| Grease lubricated | Fair |
| Water lubricated | Fair |
| Process fluid lubricated | Fai |
Technical data
|
Max. load |
Static |
250N/mm2 |
|
Dynamic |
140N/mm2 |
|
|
Max. speed |
Dry |
2m/s |
|
Lubrication |
>2m/s |
|
|
Max. PV (Dry) |
Short-time |
3.6N/mm2*·m/s |
|
Continuous |
1.8N/mm2*·m/s |
|
|
Temp. |
-195℃~+280℃ |
|
|
Friction coefficient |
0.03~0.20 |
|
|
Thermal conductivity |
42W (m·k)-1 |
|
|
Coefficient of thermal expansion |
11*10-6k-1 |
|
Availability
Bearing forms available in standard dimensions
· Cylindrical bushes
· Flanged bushes
· Thrust washers
· Flanged washers
· Sliding plates
Sliding Plates DU DU-B DP4 DP4-B DP10 DP11 DP31 PTFE Bushing
START YOUR
PROJECTWith an Application Engineer
DU Bushing, DU Bearing, Line Bearing, Ptfe Coated Bushing, DX Bush, DX Bearing
VIIPLUS Provide all types of electronic samples for customers,Metal-Polymer Composite Bearings Catalog!
Bushings,Lubricated Bearings,Composite Bearings,Metal Bearings,Compressor Bearings,Metal-polymer,Filament Wound,Plain Bearings,Flange Bearings,Polymer Bearings,Flange Bushings,Pump Bearings,Flanged Bushes,Thrust Plates,Industrial Bearings
Application
viiplus products are widely used in all industrial fields
Widely used in hydraulic and pneumatic industries, forging machine tool industry, plastics machinery industry, lifting and handling machinery, port machinery, office, fitness machinery, textile machinery, food packaging, filling machinery, chemical machinery, printing and packaging, paper making machinery, automobiles, railways Steam locomotives, shipbuilding industries, presses, metallurgical machinery, construction machinery, etc.
