David from CanadaOur company import the bronze gleitlager from viiplus china,viiplus professional team makes sure customs clearance is always smooth. They provide an accurate bronze bushing classification, handle all the paperwork,We have received the self-lubricating bronze bushings. They look well done and the high quality.
-
Valerie from CaliforniaWe import the bronze gleitlager from China to under the incoterm FOB shanghai, sometimes by Air. viiplus is a very good bronze gleitlager supplier, they are very professional and patient, after we inform the new order, they will manufacturer bronze gleitlager in time and give us the schedule , and then we just need to receive the bronze parts
-
Daisy From GermanyThe best surface finishes for Sleeve Bearing, tighter concentricity, and bronze bushings material uniformity. The good supplier of standard inch and metric sleeve bearings and bushings from china. https://www.bronzelube.com/
Railways - Plain Bearings & Self-lubricating Bushings PTFE Sleeve Bushings - Heavy Duty Linear plain bearings
Place of Origin | gleitlagerbuchsen china |
---|---|
Brand Name | VIIPLUS Sleeve & Bearing |
Certification | FIBRO Standard |
Model Number | C86300 BRONZE BUSHINGS |
Minimum Order Quantity | Standard Size Bushing No Minimum Order Quantity |
Price | Bushings High Quality Price Ratio B2B |
Packaging Details | Export carton; Wooden case ; Wood pallet. |
Delivery Time | 2~4 Weeks |
Payment Terms | T/T, L/C, Western Union, |
Supply Ability | bronze sleeve bushings, China, manufacturers, suppliers, factory, wholesale, Metallic Self Lubricating Bushings, Cast Iron Bearing, Sleeve Bushing, POM Bearing, Cast Iron Plain Bearing, Lubrication Bronze Bushing |

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xMeterial | Bronze Backed, Bronze , PTFE | Plating | Tin Or Copper |
---|---|---|---|
Quality | OEM Quality | Size | Std.&Non-std. Customized Sizes |
Application | HEAVY DUTY CAR | Type | Wrapped Bushes, Flanged Bearing, Thrust Washer |
Get A Better Quote | Tiffany@viiplus.com | Self-lubricating Bearing Bushing Manufacturer | Https://www.viiplus.com/ |
High Light | Slit Oilless Bronze Bushing, Anti Fatigue Oilless Bronze Bushing, Maintenance Free Oilless Bronze Bushing | Gleitalger | A Plain Bearing, Or More Commonly Sliding Contact Bearing And Slide Bearing, Is The Simplest Type Of Bearing, Comprising Just A Bearing Surface And No Rolling Elements. Therefore, The Journal Slides Over The Bearing Surface. The Simplest Example Of A Plain |
Bush Bearings Manufacturers Suppliers Exporters | Plain Bearings. Long, Maintenance-free Service, Manufactures Bushings In Various Designs And From Different Materials. Tiffany@viiplus.com, Bushings - Configure And Purchase - Https://www.viiplus.com/ | ||
High Light | bronze plain bearing,graphite plugged bronze bushings |
Maintenancefree Plain Bearings | PTFE Material | Steel Backed Bushing
bronzegleitlager.com with large selection ofbearing materials and dimensions
A plain bearing, or more commonly a plain bearing and a plain bearing (sometimes referred to as a fixed bearing, journal bearing, or plain bearing in railways) is the simplest type of bearing, consisting only of a bearing surface and no rolling elements.
Bimetal Wrapped Steel with Bronze Series - Metric Sliding Bearings Made in China
If you need help in selecting the best type & size bushing or sliding bearings for your particular application, please remember that design engineering and application assistance are available from VIIPLUS as part of our value-added services designed to make your job easier.
Focus On What'S Best Bushing & Sliding Bearings Product ?
Design CHINA partners in reliable tribology, VIIPLUS offers surface engineering expertise to the world in motion for plain bearings made in china and self-lubricating bushings by reducing friction loss.Metal-Polymer Composite Bearings Bronze Backed with Bronze Powder PTFE Dry Bearings /Fibre.This material meets the demanding criteria for long life and trouble-free performance with or without lubricant,
Viiplus is specialized in the manufacture and distribution of a large range of copper alloys which incorporate continuous cast and machined parts, centrifugal castings, wrought copper alloys, bars, sheets and plates, bronze wear plates We have strong ability of products design and manufacture, and specialize in large size copper alloy centrifugal casting, bronze bushings with graphite, wear plates and flange bushings for industries such as Oilless Bearings ,like Gleitlager, Boccole, Glidlager, autolubrificanti in bronzo, gerollte gleitlager,Glidlager bussningar, Bronze Bearing Bronze Gears, Bronze Valve Stems,Power & Energy, Transmission Bearings, Power & Energy, General Engineering and Marine. And so on.
VIIPLUS products meet standards
Bronze + Bronze Powder + PTFE/Fibre(DU-B)
Dry Maintenance Free Bronze Base DU-B Self Lubricating Bush SF-1B
Characteristics
· Very good wear and low friction performance over a wide range of loads, speeds and temperatures in dry running conditions
· Suitable for lubricated applications
· Suitable for linear, oscillating and rotating movements
· Bronze back offers improved corrosion resistance in humid/saline environments
· Suitable for dry running, low coefficient of friction, lower wear, good sliding characteristics, the transfer film created can protect the mating metal surface, suitable for rotary and oscillating movement. Very high chemical resistance, low absorption of water and swelling, also performs very good lubrication feature, the bronze backing provides the improved corrosion resistance comparing with VSB-10.
Strusture
1. PTFE/fibre mixture thickness 0.01~0.03mm, provides an excellent initial transfer film, which effectively coats the mating surfaces of the bearing assembly, forming an oxide type solid lubricant film.
2. Sintered bronze powder thickness 0.20-0.35mm, provides max. thermal conductivity away from the bearing surface, also serves as a reservoir for the PTFE/Fibre mixture.
3. Bronze backing, provides exceptionally high load carrying capacity, excellent heat dissipation and very good corrosion resistance.
Technical Data
Structure And Composition
· Metal-Polymer Composite Material
· Bronze Back + Porous Bronze Sinter +
· PTFE + Lead
Microsection
|
Sliding layer PTFE |
OPERATING PERFORMANCE |
|
Dry |
Very Good |
Oil lubricated |
Good |
Grease lubricated |
Fair |
Water lubricated |
Good |
Process fluid lubricated |
Fair |
* Depending on operating conditions
Bearing Properties
Max. load |
Static |
250N/mm2 |
Dynamic |
140N/mm2 |
|
Max. speed |
Dry |
2m/s |
Lubrication |
>2m/s |
|
Max. PV (Dry) |
Short-time |
3.6N/mm2*·m/s |
Continuous |
1.8N/mm2*·m/s |
|
Temp. |
-195℃~+2800℃ |
|
Friction coefficient |
0.03~0.20 |
|
Thermal conductivity |
70W (m·k)-1 |
|
Coefficient of thermal expansion |
17*10-6k-1 |
Availability
Bearing forms available in standard dimensions
· Cylindrical bushes
· Flanged bushes
· Sliding plates
Bearing forms made to order: standard forms in special dimensions, thrust washers, flanged thrust washers, half-bearings, special shapes obtained by stamping or deep drawing, customized bearing designs
Typical Applications
The typical applications covered Steel metallurgy industry such as bushes for roller grooves of successive casting machines, cement grouting pumps and screw conveyers for cement and so on.conducts the thermal build up away from the bearing surfaces.
3. Low-carbon steel.Setting the foundation of the bushings, the steel back provides exceptional stability,load carrying and heat dissipation characteristics.
