In the automotive industry, air conditioners play a crucial role in ensuring passenger comfort, especially during extreme weather conditions. One of the key components in these air conditioning systems is the compressor, which requires precision-engineered bushings to ensure smooth and efficient operation. Metal-polymer bushings, specifically designed for compressor applications, offer a unique combination of properties that make them ideal for this purpose.

Metal-polymer bushings combine the strength and durability of metal with the wear resistance and dampening properties of polymers. This combination allows them to withstand the high pressures and temperatures encountered in automotive air conditioning compressors while also providing superior wear resistance and vibration dampening.

One of the key factors in the design and selection of metal-polymer bushings for compressor applications is the assembly clearance range. This refers to the amount of space or clearance between the bushing and the mating component during assembly. Having the correct assembly clearance range is crucial for ensuring proper fit, alignment, and performance of the bushing.

Too much clearance can lead to excessive movement and vibration, while too little clearance can cause binding and wear. The optimal assembly clearance range depends on various factors such as the operating conditions, load requirements, and material properties of the bushing and mating components.

Manufacturers of metal-polymer bushings for automotive air conditioning compressors must carefully consider these factors and design the bushings to meet the specific requirements of the application. By doing so, they can provide customers with bushings that offer superior performance, durability, and reliability, ensuring smooth and efficient operation of the air conditioning system.

Metal-Polymer Anti-Friction Plain Bearings | Self-lubricating Composite Bushing From bronzegleitlager.com

Check out our online composite self-lubricating bushings product catalog with more than 10,00 products with full specifications & size available for download - all free of charge!

Composite self-lubricating bushings are made up of one of two basic compositions:

• -Based Metal-Polymer Materials
• Thermoplastic-Based Metal-Polymer Materials

AVAILABILITY

Bearing forms available in standard dimensions

• Cylindrical bushes
• Flanged bushes
• Thrust washers
• Flanged washers
• Sliding plates

Metric bearings and imperial bushings made to order: standard bushing forms in special dimensions, half-bushings, special shapes obtained by stamping or deep drawing, customized bushing designs

Air conditioner compressor bearing Metal-polymer Bushings for Compressor Applications assembly clearance range

The metal-polymer composite bearings developed by VIIPLUS have unique advantages over lead-bearing bronze or bimetallic bushings because of their self-lubricity so that contact between mating surfaces does not result in high wear or friction.Therefore, metal polymer composite bearings can provide a more reliable solution.

1.The system design

In most applications, the design of the bearing system is primarily affected by or between the shaft and the bearing surface.For compressor, clearance is an important factor affecting efficiency.The results of many years' research show that the efficiency of metal-polymer composite bearings in an effective clearance range increases more than the expected range of bimetal bearings.Since the installation tolerance range of metal polymer composite bearing is relatively large, wh it can effectively maintain or improve the efficiency will test the design strength and manufacturing strength of bearing manufacturers.And that's where VIIPLUS engineers are going.

2.Performance

The performance of the compressor's metal-polymer composite bearing depends not only on the clearance, but also on the ability of the material to withstand various speeds, loads, temperatures and corrosion effects under these application conditions.Typical bearing failure modes of compressor include wear, fatigue and corrosion.By incorporating (+ filler material) into the steel back, VIIPLUS's metal-polymer composite bearings are resistant to wear and fatigue and, in most cases, superior to conventional compressor bearings.

In addition, the formation of lubrication film and other important factors in bearing design are determined according to the conventional fluid dynamics calculation in journal bearings.In some cases, metal-polymer composite bearings show a unique phenomenon: the modulus of the bearing surface is actually lower than that of bronze, bimetal or steel.Higher loads result in greater film thickness under elastohydrodynamic lubrication (EHL) conditions than conventional journal bearings under the same conditions.Experts generally agree that polymer surface compliance can more effectively distribute load and increase film thickness.Moreover, even in the case of poor film formation, the metal-polymer composite bearing still has certain advantages because of its lubricated surface.

Finally, if properly designed, the metal-polymer composite bearing system will be more reliable than conventional bearings. is a natural lubricant that can achieve higher heat and wear resistance under edge and boundary lubrication conditions.+ polymer has higher surface compliance and better ability to cope with shaft deflection than traditional compressor bearings, thus making the system more suitable for the superposition of tolerances in compressor design.Moreover, metal polymer composite bearings can better adapt to environmental requirements to minimize environmental pollution and reduce the overall compressor cost from the overall environment.
Through the above elaboration, it can be seen that a small bearing parts can have so much impact on the service life of the overall air conditioning.We enjoy the cool behind the original so many people's wisdom and sweat, you are using the air conditioner may be VIIPLUS bearing behind the silent pay!

Typical Applications

At present, most air conditioners produced in China use screw compressor, which must meet the following conditions: high compression efficiency, few parts, small volume, light weight, low noise, low power consumption and low overall cost.In order to meet these body conditions, for the compressor in each spare parts requirements that is more stringent.High requirements for materials, processing accuracy, heat treatment, assembly process and lubrication system.

Many screw compressors currently use lead-bearing bronze or bimetallic bushings whose performance and reliability are largely dependent on lubrication conditions.If not provided with good lubrication conditions, mixed film and boundary lubrication conditions that will lead to contact between mating surfaces can produce higher friction and excessive wear.In addition, many lead-containing bronze materials are not conducive to environmental protection based on the improvement of environmental protection requirements of major air conditioning manufacturers.In view of the above situation, VIIPLUS engineers have developed a metal polymer composite bearing solution from the aspects of materials, system design and performance.

Metal-polymers Bushing have achieved commercial application in compressor design by system design adjustment and/or finishing operation control,Traditional compressor bearings such as rolling element bearings, lead-bearing bronze or bimetallic bushings are greatly affected by wear in the absence of lubrication at the bearing position.metal polymer Self-lubricated bushings making them a more reliable solution under such special conditions.In addition, compared with other journal bearings, they have other advantages such as lead free, low noise and low friction.Compared with traditional bearings, assembly clearance range is one of the biggest obstacles in metal polymer design, because it can directly affect the working efficiency.

Self-lubricating bearings High speed high load compressor solution

High speed high load compressor self-lubricating bearing solution, variable speed machine and air conditioning compressor from rolling bearings to self-lubricating bearings, replacement rate of 80%.
If the world's rolling bearings are replaced by self-lubricating bearings, the market space?

Design high speed high load compressor, without increasing the cost, to ensure that the performance of continuous improvement, you are ready?

VIIPLUS not only provides simple self-lubricating bearing and sliding bearing materials, but also finds problems, solves problems, finds the most suitable product matching solution, and prolongs the service life of the compressor and provides the performance of the compressor in application.

Construction machinery manufacturers have been troubled by severe operating environment and high regular maintenance costs.VIIPLUS USES a self-lubricating maintenance-free design that reduces the cost of bearings and systems while avoiding potential application risks.This not only saves the cost of bearing and the system itself, but also reduces the later maintenance cost.

Air condition compressor Plain Bearings  bushing self-lubricating Bearings Cylindrical Sleeve Bushes

What is du composite bearing Composite dry sliding bearings are primarily used for bearing arrangements where heavy loads have to be supported and where rotational or oscillating movements are relatively slow. Falnge diameter  Compsoite bearing standard sizes list for your reference.

General introduction of Home Air Conditioning bushing,compressor bearing bush  Composite slide Bearing

Solid polymer, filament-wound and metallic plain bearings; bushingblocks

Graphite Sleeve Bearing Factory, Custom Graphite Sleeve Bearing

Main Products: Chemical Powder , Heat Shrink Tube , Slide Bearing , Bushing Bush , Main Products: Pump Seals , Mechanical Seals , Auto Air Compressor Seals

Characteristics

VSB-10 Self-Lubricating Multilayer Composite Bushing
· Bushing material suitable for lubricated applications
· self-lubricating bushings offer very good wear and low friction performance over a wide range of loads, speeds and temperatures in dry running conditions
· Anti-friction bearing suitable for linear, oscillating and rotating movements
Material is designed to operate without supplemental lubrication and will perform excellent when lubrication is present. Low friction, low wear rate, good sliding characteristics and very low absorption are a few of the features of this material. VSB-10 bushings will support rotary, linear and oscillating motion.

Strusture

1. /Fibre mixture thickness 0.01~0.03mm. It is the contact surface for the rotating shaft. Minute partides of the layer and the sintered bronze material combine to create a solid lubricant film, which coats the shaft.


2. Sintered bronze powder thickness 0.20*0.35mm,A special composition of powdered copper is thermally fused to the steel backing. This contact layer acts as an anchor for the layer and conducts the thermal build up away from the bearing surfaces.

3. Low-carbon steel backing. Setting the foundation of the bushings, the steel back provides exceptional stability, load carrying and heat dissipation characteristics.

· Metal-Polymer Composite Self-lubricating Bushing Material
· Steel Back + Porous Bronze Sinter +
· + Lead

MICROSECTION

Bearing forms available in standard dimensions
· Cylindrical bushes
· Flanged bushes
· Thrust washers
· Flanged washers
· Sliding plates

Plain bearings are available as bushes, collar bushes, washers, strips or special designs.
Metric bearings and imperial bushings made to order: standard bushing forms in special dimensions, half-bushings, special shapes obtained by stamping or deep drawing, customized bushing designs
