Self Lubricating Bronze Sleeve Bushings For Massage Gun
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | Muscle Massage Bushing | Feature | Copper-plating/tin-plating |
|---|---|---|---|
| Material | Bronze Backing, Bronze, PTFE-layer | Size | Standard Size, Inch Size Available |
| Bearing Bushing Factory Price | Tiffany@viiplus.com | Self-lubricating Bearing Bushing Manufacturer | Https://www.viiplus.com/ |
| High Light | Self-Lubricating Sintered Bronze Bushing | Characteristic | Bronze Bushings With Grease Reservoirs ( BRO-MET, FB090, BRM10, WB800) |
| Bush Bearings Manufacturers Suppliers Exporters | Plain Bearings. Long, Maintenance-free Service, Manufactures Bushings In Various Designs And From Different Materials. Tiffany@viiplus.com, Bushings - Configure And Purchase - Https://www.viiplus.com/ | ||
| High Light | Self Lubricating Bronze Sleeve Bushings,Wear Resistant Bronze Sleeve Bushings,Massage Gun brass sleeve bushing |
||
Product Description
Bronze Sleeve Bushing For Message Gun Bronze backing, bronze, PTFE-layer
Electric Portable Deep Tissue Muscle Massage Gun
ONLINE SUPPORT
FAST DELIVERY QUALITY BUSHINGS GUARANTEE
EXPLORE THE BEST BRONZE BUSHINGS OF YOU.
Specializes in the bronze bushing and sliding bearings. We design products for, including muscle massage bushing, and other fitness bushing products. Our goal is to enhance high-quality bushing and establish a healthy lifestyle at a scientific level.
1. PTFE with Iead
2. Porous bronze sintered
3. Steel backing
4. Copper-plating/tin-plating
◎It may be used where no oil can be applied or oil is
diffificult to be applied.
◎It has the advantage of low wear, low friction and with long life.
Load will spread over a wider area due to the bearing
material’s elastic nature.
◎Low stick slip properties ensuring accuracy of machine
operation under low sliding speeds.
◎Low vibration, low noise and non-pollution in operation.
◎PTFE and Lead fifilm is transferred to the mating shaft to
improve running properties.
◎It can be used in low harness of mating shaft, so the
shafts processing is easy.
◎The machine will be compact because of the thin
thickness and low weight of the bush.
◎Electro plating is possible to prevent corrosion. It is
widely used in various sliding motions of different kind
of machines such as textile machine, tobacco machines,
hydraulic vehicles Automobiles, agriculture machines and
so on.
OUR MISSION
Combine traditional sports with modern self-lubricating bronze bushings technology to create quality sliding bearing products and protect sports health.
OUR VISION
Become a global professional brand in the sliding bearings industry, fueling human health.
OUR VALUE
Integrity, unity and cooperation, professional dedication, respect for friendship.
Combine traditional sports with modern self-lubricating bronze bushings technology to create quality sliding bearing products and protect sports health.
OUR VISION
Become a global professional brand in the sliding bearings industry, fueling human health.
OUR VALUE
Integrity, unity and cooperation, professional dedication, respect for friendship.
Product Description
|
Product Name |
SF-1 Wear Resistant Bushing DU Metal-polymer Composite Bearings PTFE Self Lubrication Bearing Bushes |
|
Material |
Steel+Bronze+PTFE+Pb+Filler |
|
Size |
We can develop according to customers' special requirement. |
|
Standard |
IATF 16949:2016, SGS, CNAS |
|
Working Temperature |
-200~+280℃ |
|
Outside Surface |
Copper/Tin |
|
Used |
printing, woven, tobacco and gymnastic machinery, pneumatic cylinder. |
Application
Bronze based DU bushing is widely used in steel metallurgy industry, cement grouting pumps and scrow conveyers of machine, marine and offshore equipment, dyeing machinery and so on.
Material Structure
1.PTFE with Pb 0.01~0.03mm
2.Porous bronze 0.2~0.3mm
3.Bronze backing 0.7~2.3mm
Technical Data
|
Specific load capacity (static) |
≤ 250 [ N/mm² ] |
|
|
Specific load capacity (dynamic) |
≤ 140 N/mm² at low speeds |
|
|
Specific load capacity(rotating oscillating) |
≤60N/m㎡ |
|
|
Friction value |
0.03 to 0.25 µ |
|
|
Temperature |
-200 to +280 [ °C ] |
|
|
Max. dry running Pv (Short-term operation) |
3.6N/m㎡﹡m/s |
|
|
Max. dry running Pv (Continuous operation) |
1.8N/m㎡﹡m/s |
|
|
Max. speed (dry running) |
2m/s |
|
|
Max. speed (Hydrodynamic operation) |
＞2m/s |
|
