CuSn8 / CuSn6 Custom Size Flat Bronze Thrust Washer Thin - Walled Self Lubricating Groove
| Place of Origin | Bushing Manufacturer |
|---|---|
| Brand Name | REPLACEMENT PLAIN BEARINGS |
| Certification | ISO 9001 |
| Model Number | FB090 BRONZE BUSHINGS |
| Minimum Order Quantity | MATE-TO-ORDER CUSTOM BUSHINGS |
| Price | Sliding Bronze Bearing Dimensions Tolerance,Stock Price |
| Packaging Details | EXPORT CARTON WOOD PALLET WOODEN CASE |
| Delivery Time | 3 - 15 BUSINESS DAYS |
| Payment Terms | T/T |
| Supply Ability | STANDARD TOLERANCE BUSHINGS |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Bushing Material | TIN BRONZE CUSN8 CUSN6 | Feature | High Temperature Resistance,Wear Resistance,corrosion Resistance |
|---|---|---|---|
| Performance | High Load Capacity And Long Life | Type | Sleeve,Flange,Thrust Washer |
| Bearing Bushing Factory Price | Tiffany@viiplus.com | Self-lubricating Bearing Bushing Manufacturer | Https://www.viiplus.com/ |
| High Light | Self-Lubricating Sintered Bronze Bushing | Characteristic | Bronze Bushings With Grease Reservoirs ( BRO-MET, FB090, BRM10, WB800) |
| Bush Bearings Manufacturers Suppliers Exporters | Plain Bearings. Long, Maintenance-free Service, Manufactures Bushings In Various Designs And From Different Materials. Tiffany@viiplus.com, Bushings - Configure And Purchase - Https://www.viiplus.com/ | ||
| High Light | oil embedded sleeve bearing,graphite sleeve bearings |
||
Product Description
The CuSn8 / CuSn6 custom size flat bronze thrust washer with thin-walled self-lubricating groove is a precision-engineered component designed to provide superior wear resistance and smooth operation in various industrial applications.
Constructed from CuSn8 or CuSn6 bronze alloys, these thrust washers offer excellent mechanical properties such as high strength, good ductility, and corrosion resistance. The thin-walled design allows for reduced weight while maintaining structural integrity, making them suitable for use in applications where space is limited.
The self-lubricating groove integrated into the thrust washer's design ensures continuous lubrication and reduced friction during operation. This not only improves the overall efficiency of the system but also extends the lifespan of the thrust washer itself.
The custom size options allow for flexibility in meeting specific application requirements. Wh it's a standard size or a unique custom dimension, these thrust washers can be tailored to fit the exact needs of your system.
With their superior wear resistance, smooth operation, and ability to self-lubricate, the CuSn8 / CuSn6 custom size flat bronze thrust washer with thin-walled self-lubricating groove is an ideal choice for applications such as hydraulic cylinders, pumps, and other heavy-duty industrial equipment.
Bronze Sleeve Bushings
Bronze CUSN8 THRUST WASHER The Premier Source for Bronze Bushings Online ,Bronze washer with diamond oil nozzle for preservation of oil lubrication. It has good anti-seize, anti-erosion and anti-seize properties, as well as bearing capacity. Its material is CuSn8P. It can be made of another tin-bronze material, and the surface can be made using a different type of oil pipe and oil groove under various operating conditions.
Thrust washers are a cost-effective alternative to thrust bearings when force speeds are moderate. They are made with a variety of bronze alloys, including:
Thrust washer CUSN8 / CUSN6 BRONZE.CuSn8 Tin Brass Bushing is made of high quality, hot-rolled, phosphor alloy pewter bronze. Sliding bearings are specially designed to withstand heavy and shock-resistant loads. The entire bearing surface consists of “drilled holes” that offer better lubrication properties and fewer maintenance periods that reduce friction both at start-up and during operation.
Tin Bronze Thrust Washer Diamond Oil Pockets made to order from china stock prices cheap online china factory manufacturer
Thrust Washer
Material: CuSn8P,CuSn6.5P Brass,copper,bronze Type: sleeve,flange bearing,thrust washer,strip,plate,sheet,custom-made
Tech. Data:
|
Size
|
Customized
|
|
Material
|
CuSn8P, Customized
|
|
Type
|
Washer
|
|
Certification
|
ISO9001
|
|
Density
|
8.8g/cm3
|
|
Hardness
|
90-150HB
|
|
Working Temperature Limit
|
-40~150℃
|
|
Max. Dynamic Load
|
100N/mm²
|
|
Max Linear Velocity(Grease)
|
2m/s
|
|
Max PV value Grease
|
2.8N/mm2·m/s
|
|
Friction Coefficient
|
0.06~0.15
|
|
Pressure strength
|
>460N/mm²
|
|
Yield Strength
|
>280 N/mm2
|
|
Mating Axis
|
Hardness≥50, Roughness 0.4~1.0
|
|
Coefficient of heat conduction
|
58W/m·K
|
|
Linear Expansion Coefficient
|
18.5×10-6/K
|
|
Application
|
hoisting, mining machinery,forest machinery, agricultural machinery
|
Request:
It is used in conditions of increased load, but low speed, for example, on agricultural, construction and engineering vehicles.
It is widely used in hoisting machines, construction machines, automobiles, tractors, trucks, machine tools and some mineral engines.
