Sliding Strips Self Lube Wear Plates Bushing Housing For Precision Cutting

Place of Origin Self Lube Bearings
Brand Name bronzelube.com
Certification Plain Sleeve Bearings Standards met: RoHS
Model Number Straight Bushing:Bronze with Embedded Solid Lubricant Material,Lead Free
Minimum Order Quantity Bronze Precision Wear Plates & Lubricating Parts made to order
Price US$0.11 - US$21.11 / Pieces,NEGOTIABLE
Packaging Details Cartons with good information lable
Delivery Time Shipped in 3-20 work days
Payment Terms TT IN ADVANCE,L/C,Western Union
Supply Ability Self Lube Bearing Manufacturing Dimensions Tolerance Assembly
Product Details
Material Carton Steel , Bronze , PTFE Characteristic Low-maintenance And Maintenance-free Plain Bearings
Size According Customer Drawing Or Samples Type Bushes, Collar Bushes, Washers, Strips Or Special Designs
Bearing Bushing Factory Price Tiffany@viiplus.com Self-lubricating Bearing Bushing Manufacturer Https://www.viiplus.com/
High Light Manufactures Wear Plates Industry Standards (VDI, JIS, NAAMS, SMC). Our Wear Plates Come In A Broad Range Of Standard Inch And Metric Wear Plate High Light Bronze Wear Plates , Self Lubricating - Special Brass Alloy
High Light

bronze wear plate

,

brass wear plate

Leave a Message
Product Description

Bushing housing sliding Bearing Special made from sliding strips using precision cutting and sheet metal working



Your recognised global partner for sliding bearing applications.
Working together to create solutions for the most demanding bearing applications.



Special productions made from VIIPLUS strips are manufactured using precision cutting and sheet metal working. A wide range of different shapes and dimensions can be manufactured from VIIPLUS materials, for example:

  • thrust washers in special dimensions

  • thrust washers with complex geometries

  • thrust washers with any inside diameter and any outside diameter up to 230 mm

  • thrust washers in other designs such as counterbores, notches or lugs

  • half-washers and washer segments

  • strip cuts

  • other strip designs, e.g. with notches or groove

  • slide path coverings

Special productions made from VIIPLUS strips are used in hydraulic applications and compressors, for example.

Other special parts made from VIIPLUS  strips

  • bent parts, e.g. angles, half-shells, U-profiles, rails

  • bearing shells

  • spherical sliding elements

  • half-shells with side elements (welding ensures firm substance-to-substance bond)

  • drawing parts, customer-specific components



Advantages of special productions made from VIIPLUS sliding strips



Sliding Strips Self Lube Wear Plates Bushing

  • small lot sizes can be manufactured

  • high material output

  • no tool costs

  • high degree of flexibility, e.g. products can be manufactured quickly

  • no elastic deformation

  • intricate contours can be created

  • neat cut edges which often do not need to be remachined







Sliding Strips Self Lube Wear Plates Bushing

Sintered PTFE and Bronze on Bronze Backing (Maintenance-free Material)

PTFE / Fibre + Bronze + Bronze Backing

Suitable for dry running, low coefficient of friction, lower wear, good sliding characteristics, the transfer film created can protect the mating metal surface, suitable for rotary and oscillating movement. Very high chemical resistance, low absorption of water and swelling, also performs very good lubrication feature



Technical Data

Physical and Mechanical Properties

Usage

Thermal Conductivity λ

60

W/mK

dry

very good

Maximum Operating Temperature Tmax

280

°C

oil lubricated

good

Minimum Operating Temperature Tmin

-200

°C

grease lubricated

fair

Compressive Yield Strength σc

300

N/mm2

water lubricated

good

Maximum Static Load Psta,max

140

N/mm2

process fluid lubricated

fair

Maximum Dynamic Load Pdyn,max

140

N/mm2



Maximum Sliding Speed V-dry

2.5

m/s

Maximum PV Factor-dry, continuous operation

1.8

N/mm2 * m/s

Maximum PV Factor-dry, intermittent operation

3.5

N/mm2 * m/s

Coefficient of friction f-dry

0.02-0.25





Coefficient of friction f-oil lubricated

0.02-0.12





Typical Applications



This material meets the demanding criteria for long life and trouble-free performance with or without lubricant, of high safety factor even.

The bronze backing provides a high corrosion resistance, anti magnetic properties and a good thermal conductivity, The bearings are particularly appropriate for high temperature environment where no oil is efficient and the machine must be under successive long period working condition.

The typical applications covered Steel metallurgy industry such as bushes for roller grooves of successive casting machines, cement grouting pumps and screw conveyers for cement and so on.
