Metal-Polymer Low Friction Plain Bearings Flange Bushing Red Coated Collar Bushes
| Place of Origin | made in china |
|---|---|
| Brand Name | VIIPLUS |
| Certification | ISO 9001 |
| Model Number | Metal-Polymer Low Friction Plain Bearings flange bushings replacment |
| Minimum Order Quantity | negotiable |
| Price | Negotiable |
| Packaging Details | EXPORT CARTON WOOD PALLET WOODEN CASE |
| Delivery Time | 7-15 work days |
| Payment Terms | T/T |
| Supply Ability | 5000000 Piece/Pieces One week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | RED Coated Bushing | Type | Split Sleeve Flange Bushings |
|---|---|---|---|
| Feature | Maintenance Free | Size | Customized，Metric Size |
| Specification | Full Sizes And Customized | Application | Automotive, Mechanic |
| Structure | Steel + Porous Bronze Sinter + | Item | Flange Bushing, Or Sleeve Bushing |
| Bearing Bushing Factory Price | Tiffany@viiplus.com | Self-lubricating Bearing Bushing Manufacturer | Https://www.viiplus.com/ |
| High Light | Coated Self Lubricating Plain Bearing, Ptfe Self Lubricating Plain Bearing, Steel Backed Self Lubricating Plain Bearing | Characteristic | Втулки скольжения (биметаллические подшипники скольжения) |
| Dry Slide Bearing | Self Lubricating Plain Bearing Work In High Temp & Submerged Applications Where Grease, Oil & Plastics Fail. Reduced Costs & Downtime. Non-galling. Increased Reliability. Run Dry & Keeps Running. | Bush Bearings Manufacturers Suppliers Exporters | Plain Bearings. Long, Maintenance-free Service, Manufactures Bushings In Various Designs And From Different Materials. Tiffany@viiplus.com, Bushings - Configure And Purchase - Https://www.viiplus.com/ |
| Highlight | Metal-Polymer Low Friction Plain Bearings Flange Bushing,low friction coefficient Sliding Bushing,TS16949 Flange Bushing |
||
Product Description
The Metal-Polymer Low Friction Plain Bearings flange bushing, equipped with red (Polytetrafluoroethylene) coated collar bushes, is a high-performance component designed for applications requiring superior wear resistance and low friction. The combination of the Metal-Polymer Low Friction Plain Bearings flange bushing and red coated collar bushes offers numerous benefits in various industrial and mechanical systems.
The Metal-Polymer Low Friction Plain Bearings flange bushing itself is a precision-engineered part that ensures accurate alignment and smooth rotation. It is typically made from high-strength materials such as steel or cast iron, which provide durability and long-lasting performance.
The red coating on the collar bushes is a significant feature of this system. is a synthetic fluoropolymer known for its excellent lubricity, chemical resistance, and temperature tolerance. The red coating not only enhances the visual identification of the bushes but also serves as an additional protective layer, further improving wear resistance and reducing friction.
The combination of the Metal-Polymer Low Friction Plain Bearings flange bushing and red coated collar bushes is particularly suitable for applications where high loads, high speeds, or harsh environments are present. The low friction properties of the coating help reduce energy loss and improve efficiency, while the wear resistance ensures long-term performance and reduced maintenance requirements.
Overall, the Metal-Polymer Low Friction Plain Bearings flange bushing with red coated collar bushes is a reliable and efficient solution for various industrial and mechanical applications. It offers superior wear resistance, low friction, and accurate alignment, ensuring smooth and reliable operation of the system.
Metal-Polymer Low Friction Plain Bearings Flange Bushings RED BUSHING, Sliding Bushings, Metal-Polymer Composite Material, Copper Plating or Tin Plating
Metal-Polymer Anti-Friction Bearings
Quality Plain Bearings and Sleeve Bearings and Material Handling Solutions, Lead-free material compliant to RoHS specifications
Bushing Type
Sleeve; Flanged
Type ( coated sliding bushing) Steel + porous bronze sinter +
Lead-free flange bushings have sliding surfaces and tin-plated steel bodies, making them an effective substitute for places that cannot or must not be lubricated. Select this type for low speed, high load applications, or low speed and high load applications. This sleeve is suitable for applications where friction and heat should be avoided. The sleeve can also be used, for example, in oil or water, and has good corrosion resistance. In addition, the model can withstand very high and very low temperatures and has a low coefficient of friction. For example, in fitness equipment.
|
Size
|
Customized
|
|
Material
|
Bronze + Bronze powder +
|
|
Color
|
Natural
|
|
Certification
|
ISO9001, TS16949
|
|
Max load capacity P
|
Static Load 250N/mm², Dynamic Load 140N/mm², Oscoillation Load 60N/mm²
|
|
Max line speed V
|
Dry Lubrication 2.5m/s,Oil Lubrication >5m/s
|
|
PV value limit
|
Dry Lubrication 1.8N/mm²· m/s,Oil Lubrication 3.6N/mm²· m/s
|
|
Friction coef u
|
Dry Lubrication 0.08~0.20, Oil Lubrication 0.02~0.12
|
|
Max Working temperature
|
-200~280℃
|
|
Mating Axis
|
Hardness >220 HB, Roughness Ra=0.4~1.25
|
|
Thermal conductivity
|
60W/(m·k)
|
|
Coefficient of linear expansion
|
18×10-6/K
|
|
Application
|
metallurgical industry, continuous casting and rolling mill, concrete machinery and spiral conveyers
|
CDIN 1494 Flange sleeve bushing, Flange Size Bushing, ROHS Approved
Sliding surface made of in tinned steel frame
Especially suitable for places where lubrication is not possible or desirable.
Metal-Polymer Low Friction Plain Bearings flanged bearing Suitable for dry running with a low coefficient of friction, low wear rate, good sliding characteristics, the transfer film created will protect the mating metal surface. Suitable for rotary and oscillating movement, high chemical resistance, lower absorption of water and reduced swelling. Also performs well with lubrication.
Material
| / Fibre + Bronze + Steel + Copper plating / tin-plating |
Technical Data
| Physical and Mechanical Properties | Usage | ||
| Maximum Operating Temperature Tmax | 280°C | dry | good |
| Minimum Operating Temperature Tmin | -200°C | oil lubricated | very good |
| Maximum Static Load Psta,max | 250N/mm² | grease lubricated | good |
| Maximum Dynamic Load Pdyn,max | 140N/mm² | water lubricated | fair |
| Maximum Sliding Speed V-dry | 2.5m/s | process fluid lubricated | good |
| Maximum Sliding Speed V-oil lubricated | 5m/s | ||
| Maximum PV Factor-dry | 1N/mm²·m/s | ||
| Maximum PV Factor-oil lubricated | 10N/mm²·m/s | ||
| Coefficient of friction f-dry | 0.04-0.25 | ||
| Coefficient of friction f-oil lubricated | 0.02-0.08 | ||
Einsatzgebiete
| This material meets the demanding criteria for long life and trouble-free performance with or without lubrication. |
| Automotive: tractors, combines, crop sprayers, earthmovers, graders and other construction, auto machines, specific uses in power steering cylinders, steering gear thrust washers, disc brakes, calipers and pistons, shock absorbers, governor linkage, windshield wiper motor, tilt gear assemblies... |
| Business machines: photocopy machines, typewriters, mail sorters, postage meter systems, computer terminal printers and peripheral equipment, automatic printing devices, mail processing machinery... |
| Hydraulics and valves: pumps including gear, rotary, water, axial piston, and other types, ball, butterfly, poppet steam, and other valves and valve trunnions... |
| Home appliances: tape recorders, refrigerators, air conditioners, cleaners, polishers, sewing machines, ovens, dishwashers, clothes washing machines...And materials handling, marine engine, packaging, textile equipment, tools...etc. |
Structures
1. /Fibre mixture thickness 0.01~0.03mm, provides an excellent initial transfer film, which effectively coats the mating surfaces of the bearing assembly, forming an oxide type solid lubricant film.
2. Sintered bronze powder thickness 0.20-0.35mm, provides Max. thermal conductivity away from the bearing surface, also serves as a reservoir for the -Fibre mixture.
3. Low-carbon steel, gives exceptionally high load carrying capacity, excellent heat dissipation.
4. Copper/Tin plating thickness 0.002mm, provides good corrosion resistance.
Characteristics
- Metal-Polymer Low Friction Plain Bearings flange bushing has low friction bushings offer good wear and low friction performance over a wide range of loads, speeds and temperatures in dry running conditions
- Very good performance in lubricated applications
- Good performance in greased applications
- Suitable for linear, oscillating and rotating movements
- Lead-free material compliant to ELV, WEEE, and RoHS specifications
- Approved to standard DIN EN 1797: 2002-02 and ISO 21010: 2004-04 (Cryogenic Vessels – Gas/Material Compatibility) for piping, valves, fittings and other components in both gaseous and liquid oxygen for up to maximum temperature of 60°C and oxygen pressure of 25 bars.
- Approved to standard FAR 25.853 and FAR 25.855 - Federal Aviation Regulations – making it suitable for interior aircraft applications
Bearing Properties
|
GENERAL |
|
Unit |
Value |
|
Maximum load, p |
Static Dynamic |
N/mm2 N/mm2 |
250 140 |
|
Operating temperature |
Min Max |
°C °C |
- 200 280 |
|
Coefficient of linear thermal expansion |
Parallel to the surface |
10-6/K |
11 |
|
Normal to the surface |
10-6/K |
30 |
Dry coated bushing
| Maximum sliding speed, U | m/s | 2.5 | |
| Maximum pU factor | N/mm2 x m/s | 1.0 | |
| Coefficient of friction | 0.04 - 0.25 * |
Oil Lubricated
|
|
|||
| Maximum sliding speed, U | m/s | 5.0 | |
| Maximum pU factor | N/mm2 x m/s | 10.0 | |
| Coefficient of friction | 0.02 - 0.08 |
Recommendations
|
|
|||
| Shaft surface roughness, Ra |
Dry Lubricated |
µm µm |
0.3 - 0.5 ≤ 0.05 - 0.4 * |
| Shaft surface hardness | Unhardened acceptable, improved bearing life > 200HB | ||
Operating Performance
| Dry | Good |
| Oil-lubricated | Very Good |
| Grease lubricated | Good |
| Water lubricated | Fair |
| Process fluid lubricated | Good |
