| Brand Name: | VIIPLUS |
| Model Number: | Flange bearing unit |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 7000000 Piece/Pieces One week |
The Pillow Block Flange Graphite Plugged Bushings are precision-engineered components designed to provide smooth and reliable operation in various industrial applications.
Constructed with a pillow block flange design, these bushings offer robust support and stability, ensuring accurate alignment and reduced vibration. The graphite-plugged material ensures excellent lubrication and wear resistance, resulting in longer service life and reduced maintenance requirements.
The Pillow Block Flange Graphite Plugged Bushings are suitable for use in high-load and high-speed applications, such as machinery, pumps, motors, and other rotating equipment. Their precision-fitted design ensures a tight seal and reduced friction, enhancing the overall efficiency and performance of the system.
With their high-quality materials and robust construction, the Pillow Block Flange Graphite Plugged Bushings are a trusted choice for industrial applications that demand reliable and long-lasting performance.
Pillow blocks bearings, Pillow Block Bearings & Inserts graphite bushings
Pillow block bronze bushing graphite bearings, flange bearing graphite units, Pillow Block Flange Graphite Bushings blocks, and take-up Pillow Block Flange Graphite Bushings units all consist of a housing with a Pillow Block Flange Graphite Bushings mounted in it. They are available in a variety of materials, mounting configurations, and various Pillow Block Flange Graphite Bushings features. Each mounted unit, including a mounted Pillow Block Flange Graphite Bushings, acts as a system to position the bearing securely for reliable operation. Read more about each type of pillow block bearing using the links below.
Reduced Lubrication Burden, Applicable to Severe Environment, Easy Installation
Bronze graphite Pillow Block demonstrates superior performance even in bad conditions and at portions where lubrication is impossible.
Self-Aligning Plain Bearing Unit
■ Easy handling enabled by complete integration into a unit
Similar to ball bearings, the OILlES pillow blocks can be easily fixed to a mounting shaft with locking screws. An inner ring provided in the OILS spherical Pillow Block Flange Graphite Bushings bore contributes to excellent friction performance irrespective of surface roughness of the mounting shaft.
■ Rational self-alignment
Machined with high accuracy with a spherical surface processing machine, the mating surface of the Bronze Bushing sphere bearing and the Pillow Block Flange Graphite Bushings housing allows smooth alignment without making deviated contact with the sliding surface, so the Pillow Block Flange Graphite Bushings performance is fully demonstrated while absorbing installation misalignment.
■ Maintenance-free operation
The Bronze Bushing pillow blocks are usable without the need for lubrication, so they can be used on food processing machines where the use of grease is undesirable and also on portions that are difficult to lubricate, without worry. (The Pillow Block Flange Graphite Bushings life can be extended by providing lubrication.)
Cast bronze and medium-duty self-lubricated flange units are available in four-bolt and two-bolt configurations.
Self-lubricated flange Pillow Block Flange Graphite Bushings units Cast bronze units: Cast bronze bearing units with self-aligning bearings of our own brand VIIPLUS, which can be relubricated using a lubricating nozzle on the carrier. They are particularly suitable for operation under special conditions (difficult environments, high speeds, high temperatures, or relatively high loads).
The flange blocks of self-lubricating Pillow Block Flange Graphite Bushings are automatically assembled with cast bronze housings. They are available in our self-lubricating bronze graphite bearings or in our carbon graphite bearings.
Self-lubricated flange Pillow Block Flange Graphite Bushings units are used when the shaft axis is perpendicular to the Pillow Block Flange Graphite Bushings mounting surface. They contain a sealed bearing that is pre-assembled in a flanged housing.
The housing contains a precision ground surface perpendicular to the Pillow Block Flange Graphite Bushings axis and two or four mounting holes, depending on the style. The bearing can be unbolted and removed, making replacement of the bearing easier and faster than traditional rotating beacons which have to be pressure fitted in a housing. self-lubricated flange Pillow Block Flange Graphite Bushings units can also withstand heavy loads, which protects the shaft from deflection, which could cause vibration or other damage.
The two-bolt self-lubricated flange Pillow Block Flange Graphite Bushings units are diamond-shaped and have two holes for mounting bolts, one on each side of the Pillow Block Flange Graphite Bushings. A line drawn across the axis of the mounting holes forms a straight line that crosses the axis of the bearing.
Four-bolt self-lubricated flange Pillow Block Flange Graphite Bushings units have four mounting holes arranged radially around the Pillow Block Flange Graphite Bushings axis. Four-bolt self-lubricated flange Pillow Block Flange Graphite Bushings units usually have round or square housings.
| Shaft Size | B | C | D | E | H | J | M | S |
| 3/4" | 4-13/32 | 1-5/8 | 2-5/32 | 3-17/32 | 7/16 | 13/32 | 1-3/32 | 1-1/8 |
| 7/8" | 4-7/8 | 1-13/16 | 2-15/32 | 3-57/64 | 1/2 | 7/16 | 1-5/32 | 1-7/32 |
| 15/16" | 4-7/8 | 1-13/16 | 2-15/32 | 3-57/64 | 1/2 | 7/16 | 1-5/32 | 1-7/32 |
| 1" | 4-7/8 | 1-13/16 | 2-15/32 | 3-57/64 | 1/2 | 7/16 | 1-5/32 | 1-7/32 |
| 1-1/8" | 5-9/16 | 2-1/16 | 3 | 4-19/32 | 9/16 | 7/16 | 1-5/16 | 1-27/64 |
| 1-3/16" | 5-9/16 | 2-1/16 | 3 | 4-19/32 | 9/16 | 7/16 | 1-5/16 | 1-27/64 |
| 1-1/4" | 6-23/32 | 2-3/8 | 3-13/32 | 5-1/8 | 5/8 | 1/2 | 1-15/32 | 1-45/64 |
| 1-3/8" | 6-23/32 | 2-3/8 | 3-13/32 | 5-1/8 | 5/8 | 1/2 | 1-15/32 | 1-45/64 |
| 1-7/16" | 6-23/32 | 2-3/8 | 3-13/32 | 5-1/8 | 5/8 | 1/2 | 1-15/32 | 1-45/64 |
| 1-1/2" | 6-23/32 | 2-3/8 | 3-13/32 | 5-1/8 | 5/8 | 1/2 | 1-15/32 | 1-45/64 |
| 1-11/16" | 5-27/32 | 2-13/16 | 3-7/8 | 5-3/4 | 11/16 | 9/16 | 1-17/32 | 1-23/32 |
| 1-3/4" | 5-27/32 | 2-13/16 | 3-7/8 | 5-3/4 | 11/16 | 9/16 | 1-17/32 | 1-23/32 |
| 1-15/16" | 7-7/16 | 3-1/16 | 4-9/32 | 6-3/16 | 23/32 | 9/16 | 1-7/8 | 1-63/64 |
| 2" | 7-7/16 | 3-1/16 | 4-9/32 | 6-3/16 | 23/32 | 9/16 | 1-7/8 | 1-63/64 |
| 2-3/16" | 8-5/8 | 3-3/8 | 5 | 7-1/4 | 5/8 | 5/8 | 1-1/2 | 2-9/16 |
| Shaft Size | B | B.C. | C | D | E | H | J | M | S |
| 3/4" | 3-3/8 | 3-17/32 | 1-5/8 | 2-1/8 | 2-1/2 | 7/16 | 3/8 | 1-3/32 | 1-3/16 |
| 7/8" | 3-3/4 | 3-57/64 | 1-13/16 | 2-11/32 | 2-3/4 | 1/2 | 7/16 | 1-5/32 | 1-7/32 |
| 15/16" | 3-3/4 | 3-57/64 | 1-13/16 | 2-11/32 | 2-3/4 | 1/2 | 7/16 | 1-5/32 | 1-7/32 |
| 1" | 3-3/4 | 3-57/64 | 1-13/16 | 2-11/32 | 2-3/4 | 1/2 | 7/16 | 1-5/32 | 1-7/32 |
| 1-1/8" | 4-1/4 | 4-19/32 | 2-1/16 | 3 | 3-1/4 | 9/16 | 7/16 | 1-5/16 | 1-3/8 |
| 1-3/16" | 4-1/4 | 4-19/32 | 2-1/16 | 3 | 3-1/4 | 9/16 | 7/16 | 1-5/16 | 1-3/8 |
| 1-1/4" | 4-5/8 | 5-1/8 | 2-3/8 | 3-13/32 | 3-5/8 | 5/8 | 1/2 | 1-15/32 | 1-21/32 |
| 1-3/8" | 4-5/8 | 5-1/8 | 2-3/8 | 3-13/32 | 3-5/8 | 5/8 | 1/2 | 1-15/32 | 1-21/32 |
| 1-7/16" | 4-5/8 | 5-1/8 | 2-3/8 | 3-13/32 | 3-5/8 | 5/8 | 1/2 | 1-15/32 | 1-21/32 |
| 1-1/2" | 4-5/8 | 5-1/8 | 2-3/8 | 3-13/32 | 3-5/8 | 5/8 | 1/2 | 1-15/32 | 1-21/32 |
| 1-11/16" | 5-3/8 | 5-32/64 | 2-13/16 | 4-1/8 | 4-1/8 | 11/16 | 9/16 | 1-17/32 | 1-11/16 |
| 1-3/4" | 5-3/8 | 5-32/64 | 2-13/16 | 4-1/8 | 4-1/8 | 11/16 | 9/16 | 1-17/32 | 1-11/16 |
| 1-15/16" | 5-5/8 | 6-3/16 | 3-1/16 | 4-7/16 | 4-3/8 | 22/32 | 9/16 | 1-7/8 | 1-29/32 |
| 2" | 5-5/8 | 6-3/16 | 3-1/16 | 4-7/16 | 4-3/8 | 22/32 | 9/16 | 1-7/8 | 1-29/32 |
| 2-3/16" | 6-3/8 | 7-1/4 | 3-3/8 | 4-3/4 | 5-1/8 | 25/32 | 5/8 | 1-15/16 | 2-3/16 |
| 2-7/16" | 6-7/8 | 7/15/16 | 3-3/4 | 5-3/8 | 5-5/8 | 27/32 | 5/8 | 2-1/16 | 2-3/8 |
| 2-1/2" | 6-7/8 | 7/15/16 | 3-3/4 | 5-3/8 | 5-5/8 | 27/32 | 5/8 | 2-1/16 | 2-3/8 |
| 2-15/16" | 7-5/8 | 8-31/64 | 4-3/16 | 6-1/2 | 6 | 3/4 | 3/4 | 1-15/16 | 2-49/64 |
| 3" | 7-5/8 | 8-31/64 | 4-3/16 | 6-1/2 | 6 | 3/4 | 3/4 | 1-15/16 | 2-49/64 |
The use of a twin-screw flange Pillow Block Flange Graphite Bushings assembly
Two-bolt self-lubricated flange Pillow Block Flange Graphite Bushings units can be found in a variety of applications, including agriculture, bakery, construction, forestry, marine, and textile equipment.
Advantages of using self-lubricated flange Pillow Block Flange Graphite Bushings units
Self-lubricated flange Pillow Block Flange Graphite Bushings units are available with the option of metric or inch insert. Their design allows you to adjust moderate initial misalignment.
Specification
| Material | Cast bronze |
| Inside Diameter | 30mm |
| Length | 148mm |
| Width | 80mm |
| Depth | 40.2mm |
| Number of Mount Holes | 2 |
| Mount Hole Size | 16 mm |
| Mount Hole Centre-to-Centre | 117mm |
Advantages of Using self-lubricated flange bearing units
Self-lubricated flanged bearing units are available in a wide range of styles for various applications, with metric or imperial options. Their design allows for moderate initial displacement.
Normal Pillow Block Flange Graphite Bushings Application
Four-bolt self-lubricated flange bearing units for normal operating conditions (self-lubricated flange bearing units Pillow Block Flange Graphite Bushings from a mounted ball bearing assembly or the "Bearings with Housing" family) are among the most common bearing assemblies. Self-lubricated flange bearing units can be found in a variety of applications, including, but not limited to, agricultural, bakery, construction, forestry, marine, and textile equipment.
Four-bolt self-lubricated flange bearing units
Four-bolt self-lubricated flange bearing units made of the medium-heavy cast bronze are available in different sizes to meet a wide range of applications. Self-lubricated flange bearings unit is used in many industries and can be used in machines as diverse as packaging systems, conveyor systems, agricultural equipment, construction machinery, heat treatment systems, forestry systems, and marine applications.
Pillow Block Flange Graphite Bushings Specification
| Material | Cast bronze |
| Inside Diameter | 25.4mm |
| Length | 3-3/4in |
| Width | 3-3/4in |
| Depth | 1-13/62in |
| Number of Mount Holes | 4 |
| Mount Hole Size | 15/32 in |
| Mount Hole Centre-to-Centre | 69.8mm |
This type of Pillow Block Flange Graphite Bushings is widely used in agricultural machinery, construction machinery, textile machinery, food machinery, transport equipment, hollow glass production lines, engineering, and engineering projects, inkjet printers, spice processing equipment, heat exchangers, water treatment equipment, pumps, electric welder, household sewing machines, tables, sorting screen, plating equipment, polishing machines, rubber molding machine, tableting machine, plastic rolling machine, agricultural machinery parts, granule drying equipment, etc.
