Steel Backing Bimetal Bearings Oil Grooves & Indentations Customer Size Wrapped Bushes
|Place of Origin||Bimetal Bearing Manufacturers|
|Brand Name||bimetal SAE-797 SAE 48 SAE-799 bushings|
|Certification||Bimetal Bush Material CuPb10Sn10、CuPb6Sn6Zn3 CuPb24Sn4...|
|Model Number||JF800 JF720 JF700 Bimetal Lead-Free Plain Bearings|
|Minimum Order Quantity||800 Piece/Pieces (Min. Order)|
|Price||$0.20 - $2.00 / Pieces ,Negotiable|
|Packaging Details||export & import bimetal bushings International carton standard|
|Delivery Time||Manufacture Bimetal Bushing In Stock, Delivered Within Days.|
|Payment Terms||TT IN ADVANCE Western Union|
|Supply Ability||casting bimetal bushing, China, manufacturers, suppliers, factory, wholesale, Metric Self Lubricating Bushing, Self Lubricating Bushings, Journal Bronze Bearings, Bimetal With Graphite Bearing, Metallic Bearings, Flanged Bimetallic Plain Bearing|
Contact me for free samples and coupons.
Wechat: 0086 18588475571
If you have any concern, we provide 24-hour online help.x
|Meterial||Low Carbon Steel Wth Tin-Lead-Bronze Alloy (CuSn10Pb10)||Plating||Tin Plating, Cooper Plating|
|Type||Bushes Wrapped Bushes With Flange Strips||Application||Wheel Excavator Gear Box, Gear Pump Bushings|
|Bearing Bushing Factory Price||Tiffany@viiplus.com||Self-lubricating Bearing Bushing Manufacturer||Https://www.viiplus.com/|
|High Light||Steel Backed Bronze Bushing, Bimetallic Bushes||Bimetallic Bearing Bushing||Bimetal Bearing With Steel Backing And Bronze Overlay • Particularly Suitable For High ... Bimetal Plain Bearings To Standard SAE 792|
|Bush Bearings Manufacturers Suppliers Exporters||Plain Bearings. Long, Maintenance-free Service, Manufactures Bushings In Various Designs And From Different Materials. Tiffany@viiplus.com, Bushings - Configure And Purchase - Https://www.viiplus.com/|
VIIPLUS International China Specialized Metal Sintered Steel Backed Bronze Bushings sourcing made to order online from china
Bimetallic composite bearings to high-quality low-carbon steel substrate, the surface of the sintered copper alloy with low friction characteristics (CuPb10Sn10, CuPb6Sn6Zn3, CuPb24Sn4, CuPb30, AlSn20Cu, CuSn8Ni....) as bearing wear layer
Download Our Complete Bi Metal Bushing Catalogue china
The Self-Lubrciating Bearings of Technology.As China Manufacturer in the field of oilless bushing technology, VIIPLUS Oilless bearing suppliesa range of plain bearings products that has gained an excellent reputation for reliability and performance.
Steel backing Bimetal Bearings Oil grooves & indentations Customer Size Wrapped bushes
BiMetal Made in China JF 800 Steel backing with CuPb10Sn10 or CuSn6Zn6Pb3 liners. This grade is best applied in lubricated pin bushings for application in suspensions, off road construction equipment, auto chassis points and areas where speeds are medium range but high impact is possible. Bimetal sleeve bushing are made of bronze or steel backing structures with sintered liners of different compositions. All of these bushes are rolled bearings like our standard made in china products.
Idler Roller Series Bushings JF-800 Bimetal Bearing Bushes Sizes | Self Lubricating Bearing
Bimetallic Bearing's steel-bronze-compound material with indents as reservoir for the grease. JF800 Bimetallic Bearings has high load capacity, very good resistance to fatigue strength at higher temperatures. JF800 Bimetallic Bearings is applicable in rough operation conditions.
Bimetal self-lubricating bearing is a copper alloy layer with excellent wear resistance, which is based on high quality low carbon steel and sintered on the surface.The surface of the copper alloy layer can be processed into various types of oil groove, oil storage pit, oil hole and so on according to the working conditions, so as to be suitable for the occasions where it is impossible to oil continuously or difficult to oil.The copper alloy layer can provide two kinds of alloy materials including lead and lead-free.
Bimetal bearing this product is one of the most powerful bearing capacity of double alloy bearing, the balance bridge bushing and gasket of heavy duty vehicle; The moving wheel and supporting wheel of the bulldozer; Automobile steel sheet bushing, all use this product. It is a widely used high - load low-speed sliding bearing.bimetal bearing is made of low carbon steel plate and surface sintered CuPb10Sn10 or cusn6zn6zn6pb3 material.
Bimetal bearing with steel backing and bronze overlay
Particularly suitable for high specific loads with oscillating motion and low frequency
Applicable in rough operation conditions
High load capacity, very good resistance to fatigue strength at higher temperatures
VSB-80 Bimetallic composite bearings
Steel shell backed with a lead bronze lining bearing material for oil lubricated applications. This material has high load capacity and good fatigue properties. It is widely used in automotive applications such as compressors, steering gear, power steering, pedal bearings, king-pin bushes, tailgate pivots, mechanical handling and lifting equipment, hydraulic motors, agricultural machinery etc.
1.Sintered bronze lazer: God wear resistance and excellent load carrying capacity.
2.Steel backing:Setting the foundation of the bushings,the steel back provides exceptional stability, load carrying and heat dissipation characteristics.
his material is recommended to be used under the medium speed and medium load condition with oil or grease lubricating. It is widely used for motor rod ends, Kingpin bushing, undercarriage rollers, hydraulic cylinder rod eyes of construction machines and spherical joint bearings of agricultural machines. Because this material is with lead, the specific parts are not allowed to be used according to certain laws or regulations.
Bimetal Bushings Size
|10||12||1||12 +0.065||10 +0.022||12 +0.018||10 -0.013||0.5||0.3||1010||1015||1020|
|12||14||14 +0.065||12 +0.027||14 +0.018||12 -0.016||0.5||0.3||1210||1215||1220|
|14||16||16 +0.065||14 +0.027||16 +0.018||14 -0.016||0.5||0.3||1410||1415||1420|
|15||17||17 +0.065||15 +0.027||17 +0.018||15 -0.016||0.5||0.3||1510||1515||1520|
|16||18||18 +0.075||16 +0.027||18 +0.018||16 -0.016||0.8||0.4||1610||1615||1620|
|18||20||20 +0.075||18 +0.033||20 +0.021||18 -0.016||0.8||0.4||1810||1815||1820||1825|
|20||23||1.5||23 +0.075||20 +0.033||23 +0.021||20 -0.033||0.8||0.4||2010||2015||2020||2025|
|22||25||25 +0.075||22 +0.033||25 +0.021||22 -0.033||0.8||0.4||2210||2215||2220||2225|
|24||27||27 +0.075||24 +0.033||27 +0.021||24 -0.033||1||0.5||2410||2415||2420||2425||2430|
|25||28||28 +0.075||25 +0.033||28 +0.021||25 -0.033||1||0.5||2515||2520||2525||2530|
|26||30||2||30 +0.075||26 +0.033||30 +0.021||26 -0.033||1||0.5||2615||2620||2625||2630|
|28||32||32 +0.085||28 +0.033||32 +0.025||28 -0.033||1||0.5||2815||2820||2825||2830||2840|
|30||34||34 +0.085||30 +0.039||34 +0.025||30 -0.039||1.2||0.6||3015||3020||3025||3030||3040|
|32||36||36 +0.085||32 +0.039||36 +0.025||32 -0.039||1.2||0.6||3215||3220||3225||3230||3240|
|35||39||39 +0.085||35 +0.039||39 +0.025||35 -0.039||1.2||0.6||3520||3525||3530||3540||3550|
|38||42||42 +0.085||38 +0.039||42 +0.025||38 -0.039||1.2||0.6||3820||3825||3830||3840||3850|
|40||44||44 +0.085||40 +0.039||44 +0.025||40 -0.039||1.2||0.6||4020||4025||4030||4040||4050|
|45||50||2.5||50 +0.085||45 +0.039||50 +0.025||45 -0.039||1.5||1||4525||4530||4540||4550|
|50||55||55 +0.100||50 +0.039||44 +0.030||50 -0.039||1.5||1||5030||5040||5050||5060|
|55||60||60 +0.100||55 +0.046||60 +0.030||55 -0.046||1.5||1||5530||5540||5550||5560|
|60||65||65 +0.100||60 +0.046||65 +0.030||60 -0.046||1.5||1||6030||6040||6050||6060|
|65||70||70 +0.100||65 +0.046||70 +0.030||65 -0.046||1.5||1||6530||6540||6550||6560|
|70||75||75 +0.100||70 +0.046||75 +0.030||50 -0.046||1.5||1||7030||7040||7050||7060||7080|
|75||80||80 +0.100||75 +0.046||80 +0.035||75 -0.046||1.5||1||7530||7540||7550||7560|
|80||85||85 +0.100||80 +0.054||85 +0.035||80 -0.054||1.5||1||8040||8050||8060||8080|
|84||90||3||90 +0.120||84 +0.054||90 +0.035||84 -0.054||1.8||1.2||8440||8450||8460||8480|
|89||95||95 +0.120||89 +0.054||95 +0.035||89 -0.054||1.8||1.2||8940||8950||8960||8980|
|94||100||100 +0.120||94 +0.054||100 +0.035||94 -0.054||1.8||1.2||9450||9460||9480|
|99||105||105 +0.120||99 +0.054||105 +0.035||99 -0.054||1.8||1.2||9950||9960||9980|
|104||110||110 +0.120||104 +0.054||110 +0.035||104 -0.054||1.8||1.2||10450||10460||10480|
|109||115||115 +0.120||109 +0.054||115 +0.035||109 -0.054||1.8||1.2||10950||10960||10980|
|114||120||120 +0.120||114 +0.054||120 +0.040||114 -0.054||1.8||1.2||11450||11460||11480|
|119||125||125 +0.170||119 +0.054||125 +0.040||119 -0.054||1.8||1.2||11950||11960||11980|
|123||130||3.5||130 +0.170||123 +0.054||1130 +0.040||123 -0.054||2||1.5||12350||12360||12380||123100|
|128||135||135 +0.170||128 +0.063||135 +0.040||128 -0.063||2||1.5||12850||12860||12880||128100|
|133||140||140 +0.170||133 +0.063||140 +0.040||133 -0.063||2||1.5||13350||13360||13380||133100|
|138||145||145 +0.170||138 +0.063||145 +0.040||138 -0.063||2||1.5||13860||13880||138100|
|143||150||150 +0.170||143 +0.063||150 +0.040||143 -0.063||2||1.5||14360||14380||143100|
|148||155||155 +0.170||148 +0.063||155 +0.040||148 -0.063||2||1.5||14860||14880||14890|
|153||160||160 +0.170||153 +0.063||160 +0.040||153 -0.063||2||1.5||15360||15380||15390|
|158||165||165 +0.170||158 +0.063||165 +0.040||158 -0.063||2||1.5||15860||15880||158100|
|163||170||170 +0.170||163 +0.063||170 +0.040||163 -0.063||2||1.5||16360||16380||163100|
|168||175||175 +0.170||168 +0.063||175 +0.040||168 -0.063||2||1.5||16860||16880||168100|
|173||180||180 +0.170||173 +0.063||180 +0.040||173 -0.063||2||1.5||17360||17380||173100|
