Sliding Bushings Ploymer Plain Sleeve Bearing Strips Metal Polymer Bearings

Place of Origin Plain Bearing Material
Brand Name China Plain-Bearing
Certification DIN 1494/ISO 3547
Model Number Wrapped composite sliding bearing
Minimum Order Quantity 500 Piece/Pieces
Price flat strip material inch sizes Manufacturers,Factory Price
Packaging Details Shipment Bushing Packing: Cartons per Wooden Case or Pallet.
Delivery Time 15~20 Days
Payment Terms TT IN ADVANCE
Supply Ability 1000000 Piece/Pieces per Month Plain-Bearing Bushing

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Wear,Dry,Low Resistance Meterial Low-Carbon Steel + Porous Bronze + Yellow POM Strips
Plating Tin Or Copper Type Wrapped Bushes, Thrust Washer
Special Use High-strength Steel Plate Customized Available As Per Drawing
Bearing Bushing Factory Price Tiffany@viiplus.com Self-lubricating Bearing Bushing Manufacturer Https://www.viiplus.com/
Bush Bearings Manufacturers Suppliers Exporters Plain Bearings. Long, Maintenance-free Service, Manufactures Bushings In Various Designs And From Different Materials. Tiffany@viiplus.com, Bushings - Configure And Purchase - Https://www.viiplus.com/
High Light

du strip

,

plain sleeve bearing strips

Leave a Message
Product Description

Sliding bushings, polymer plain sleeve bearing strips, and metal-polymer bearings are all types of bearings that are designed to provide smooth and reliable operation in various industrial applications.
Sliding bushings are mechanical components that are typically made of a polymeric material or a combination of metal and polymer. They are used to reduce friction between moving parts, such as shafts and housings. Sliding bushings are often used in applications where there is a need for low-friction, high-load-bearing capacity, and/or long-lasting durability.
Polymer plain sleeve bearing strips are similar to sliding bushings but are specifically designed as thin, flat strips that can be installed into a sleeve or housing. These bearing strips are typically made of polymeric materials like POM (Polyoxymethylene) or nylon, which offer excellent wear resistance and low friction properties. Polymer plain sleeve bearing strips are commonly used in applications where a thin, lightweight bearing solution is required.
Metal-polymer bearings are a type of composite bearing that combines the strength and durability of metal with the low-friction and wear-resistant properties of polymeric materials. These bearings are often used in applications where high loads, pressures, and/or temperatures are present. The metal components provide structural support while the polymeric material provides the necessary lubrication and wear resistance.
All three types of bearings — sliding bushings, polymer plain sleeve bearing strips, and metal-polymer bearings — are designed to provide smooth and reliable operation in various industrial applications. The choice of bearing type will depend on the specific requirements and operating conditions of the application, including load capacity, speed, temperature, and lubrication requirements.



Self-Lubricating Bronze Bushing


Sliding bearing, sleeve bearing & plain bearing mateiral flat strips sheet,bearing-technology,sliding-bearings plates
VIIPLUS are specialists in the field of sliding bronze bearing technology. We offer a wide range of high-quality sliding bearings. More information?https://www.viiplus.com
Non-lead boundary lubrication bearing is improved on the basis of LIKE DX BUSHINGS.It can be applied to the field where non-lead is required.Now it's widely used in textile machines,auto operating parts and other middle speed,middle load and grease lubrication occasions.

The structure of this self-lubricated bearing material strip plate sheet consists of spherical powdered bronze sintered onto a steel backing and POM polyacetal resin impregnated into the surface.This bushing is filled with lubricant before installation, to which a small amount of lubricant is added at predetermined intervals to allow it to withstand long-term operation.


Self-Lubricating Bronze Bushing



VSB-20 Strips, Slide Bearing Strip


Plain Bearings & Sliding Bearing Strips
Our VIIPLUS range of bearing strip is suitable for rotary and oscillating movement applications.
The VIIPLUS bearing strip is made from carbon steel with a sintered bronze layer and an acetal co-ploymer layer.
Our machining service is able to produce non-standard sizes to suit customer specific requirements.
Please contact us for information on sizes.


Features


Low friction for smooth rotation at startup and at low speed under high load conditions.
Seizure-free sliding surfaces.
Excellent shaft misalignment tolerance.
Ability to withstand impact loads.
Low friction.Damage prevention to shaft.
Virtually wear-free bearing surface with minimal lubricant.



Characteristics


VIIPLUS range of wrapped POM lined bearings are suitable for rotary and oscillating movement applications. They benefit from long re-lubrication intervals, no absorption of water, outstanding damping behaviors and have a low suceptibility to edge loading.
Strips PAS are available as an even material section. This material section can be used to make sliding elements in a variety
of shapes.

  • Cylindrical bushes

  • Thrust washers

  • Strips



Strusture


Our wrapped Ploymer lined bearings have a high wear resistance and low friction even with very small quantities of lubricant
The surface carries a pattern of circular indents which should be filled with grease on assembly
Low carbon steel gives exceptionally high load carrying capacity and excellent heat disspation

Our VIIPLUS range of wrapped acetal bearings can hugely reduce maintenance costs on projects large and small and are stocked in metric plain, imperial plain, metric washers. Imperial washers, metric strip and imperial strip.


Typical Applications



  • Rear chassis hinges

  • Articulation joints

  • Spindles of drills

  • Gearboxes & clutches

  • Grinding and milling machines

  •

Technical Data





  • Metal-Polymer Composite Bushing Material

  • Steel Back + Porous Bronze Sinter + POM with Lubrication Indents




Sliding Bushings Ploymer Plain Sleeve Bearing Strips Metal Polymer Bearings 1

Sliding layer POM
with or without
lubricant indents
for machining
Porous Bronze
Sinter
Steel Back





OPERATING PERFORMANCE

Dry

Poor

Oil lubricated

Good

Grease lubricated

Very Good

Water lubricated

Poor

Process fluid lubricated

Poor



Avaibearing Properties



GENERAL



Unit

Value

Maximum load

Static
Dynamic

N/mm2
N/mm2

250
140

Operating temperature

Min
Max

°C
°C

- 40
110



GREASE LUBRICATED







Maximum sliding speed



m/s

>2.0

Coefficient of friction





0.05 – 0.20



Max. load

Static

250N/mm2

Dynamic

140N/mm2



Rotaing oscillating

60N/mm2

Max. speed

Dry

2m/s

Lubrication

>2m/s

Max. PV (Dry)

Short-time

3.6N/mm2*·m/s

Continuous

1.8N/mm2*·m/s

Temp.

-195℃~+280℃

Friction coefficient                         Dry

0.03~0.20

                                                      Lubrication

>2m/s

Thermal conductivity

42W (m·k)-1

Coefficient of thermal expansion

11*10-6k-1




Availability



Self-Lubricating Bronze Bushing



Bearing forms available in standard dimensions


· Cylindrical bushes
· Thrust washers
· Sliding plates

Metric bearings and imperial bushings made to order: standard bushing forms in special dimensions, half-bushings, special shapes obtained by stamping, bearings with locating notches, lubricant holes and machined grooves, customized bushing designs



Wrapped Lined Bearings Sizes
