C83600 Bronze Graphite Bushings CuSn5Pb5Zn5 USA ASTM UNS Material Cast

Place of Origin Graphite Bearings Manufacturers
Brand Name ,MISUMI,DAIDO,SELF LUBE,,FIBRO STANDARD REPLACEMENT BEARING
Certification DIN 1850/ISO 4379, UNITED STATES UNS STANDARD,C86300
Model Number solid bushing, bronze with lubricant plugs embedded Maintenance-free
Minimum Order Quantity NEGOTIABLE
Price Price Graphite Bushing Parts, (SAE 660) Leaded Tin Bronze Bearings,863 (SAE 430B) 862 (SAE 430A)Manganese Bronze
Packaging Details BUSHING EXPORT CARTONS,WOODEN CASE, SPECIFY REQUIREMENTS
Delivery Time FAST DELIVERY
Payment Terms TT IN ADVANCE
Supply Ability Bronze Bushings Online • Sliding Bearings Manufacturers • Self-lubricating Bushing Suppliers

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Marerial CuSn5Pb5Zn5 Bronze Graphite Bushing Size Inch Size Bushings
Standard Size C83600 CuSn5Pb5Zn5 Type PLUGGED CAST BRONZE
Bearing Bushing Factory Price Tiffany@viiplus.com Self-lubricating Bearing Bushing Manufacturer Https://www.viiplus.com/
Item Bronze Grafitado Graphite Plugged Bushings Purchase Oilless Bush #500 Spherical Bearing (SPS) From China, Factory Automation & Metal Molding Parts, Industrial Tools And Consumables.
Bush Bearings Manufacturers Suppliers Exporters Plain Bearings. Long, Maintenance-free Service, Manufactures Bushings In Various Designs And From Different Materials. Tiffany@viiplus.com, Bushings - Configure And Purchase - Https://www.viiplus.com/
High Light

graphite impregnated bronze bushings

,

graphite filled bronze bushes

Leave a Message
Product Description

C83600 bronze graphite bushings are precision-engineered components that offer exceptional wear resistance and lubricity in a variety of industrial applications. These bushings are cast from CuSn5Pb5Zn5 alloy, which is specified by the USA ASTM UNS material standard, ensuring consistency in material composition and properties.
The CuSn5Pb5Zn5 alloy, also known as tin-based lead-bearing bronze, is a highly versatile material that combines the benefits of tin, lead, and zinc. Tin provides excellent corrosion resistance and wear durability, while lead improves machinability and reduces friction. Zinc further enhances the alloy's strength and ductility.
The addition of graphite to the CuSn5Pb5Zn5 alloy results in a self-lubricating bushing that can operate with minimal external lubrication. This not only reduces maintenance requirements but also extends the bushing's service life.
C83600 bronze graphite bushings are widely used in applications where smooth and reliable operation is critical, such as machinery, pumps, and other rotating equipment. They are suitable for both dry and wet environments and can withstand high temperatures and pressures.
By adhering to the USA ASTM UNS cast standard, C83600 bronze graphite bushings ensure consistent quality and performance, making them a reliable choice for industrial applications requiring precision-engineered bushings.


Graphite Plugged Bushings


While VIIPLUS is recognized as the supplier in pipe Graphite Plugged Bushings manufacturing equipment, our Graphite Plugged Bushings product range includes equipment for a wide variety of customers.

Materials:Cast Bronze Bearring Products  - Product Forms - Size Range.VIIPLUS BUSHINGS offer the best combination of strength/stiffness with flexibility/elasticity and abrasion resistance. The thermoplastic grade is a full form bearing that can operate at higher pressures. Regardless of grade or configuration, VIIPLUS bearings do not require grease or oil lubrication in dry or wet conditions.


What is the characteristic of graphite bronze plate?


Copper bronze plate is just a broad name, it is a sliding rolling machine used a temporary cut resistance tog with the transmission thrust and support fixed parts.
In some special local, equivalent to the role of wear plate, such as overloading, low speed, large mechanical load impact local, smooth and fine, life spans are long, on the shaft of the copper sleeve bearing is the function of, also known as sliding bearing, bearing was operating under sliding resistance, relative shaft is tumbling, general requirements for a smooth system operation or use the smooth bearing.
Plain bearings are stable, reliable and noiseless. Under the condition of smooth liquid, the sliding surface is separated by smooth oil without direct contact, and the friction loss and surface wear can be greatly reduced.


Graphite Bronze Plate


Graphite copper sleeve is primarily based on high strength copper alloy (also known as JDB solid inlaid self-smooth bearing,wear plate), so what are the characteristics of graphite bronze wear plate?
The method of embedding the specially formulated solid smooth material through the matrix is used as the smooth medium to replace the traditional oil groove copper sleeve. Can not easily refueling, long - term lack of oil may be oil - free environment to use, to make up for the traditional copper sleeve needs to fuel the lack of punctuality.
It has the characteristics of high bearing capacity, shock resistance, high temperature resistance, strong self-smoothing talent, etc. It is especially suitable for heavy load, low speed, reciprocating or shaking, etc. It is difficult to smooth and form oil film.
Because it has a high hardness and strength, and low cost, in the case of low speed heavy-duty use life than the general copper cover is twice higher, so by the majority of customers like. Different scales and materials can be customized according to customer requirements.
C83600 Bronze Graphite Bushings CuSn5Pb5Zn5 USA ASTM UNS Material Cast
QSn5-5-5 Alloy Bronze Bushings
C83600 Bronze Graphite Bushings Leaded Red Brass Cast Bronze Bearings | CuSn5Pb5Zn5 material B30-92 USA ASTM(UNS)
Engineered for a Longer More Reliable Service Life
C83600 Bronze Graphite Bushings
graphite plugged bronze bushings

The C83600 tin bronze sleeve has high ductility, good casting quality and high workability.In addition, it is easy to weld and has good thermal and electrical conductivity.
It has excellent corrosion resistance, making it an ideal choice for Marine applications.
It is used in seawater valves and Marine components.

Plug graphiting is accomplished by drilling a rowed, staggered hole configuration through the bearing wall and pressing graphite into these holes and hard baking. The size and number of drilled holes and the number of rows is determined by the bearing length and diameter.


  • Inch Sleeves
  • Metric Sleeves
  • Metric Flanges
  • Metric Washers


Solid self-lubricating bearing with graphite plug insert | Graphite copper sleeve bushings
Graphite Plugged Bronze Bushings are all self-lubricating and maintenance free. These bushings are machined out of continuous cast bronze and plugged with solid lubricant plugs. A bushing and it's mating surface should always be seperated by a film of lubricant.Many of VIIPLUS’s components use graphite. Here is what you need to know about it. Graphite is ordinary carbon in a highly unusual form, a two-dimensional crystal. Think of it as a one-atom thick sheet. A piece of graphite is a stack-up of these sheets. A graphite pencil lead feels oily because these one-atom thick sheets are very slippery.


  • Wear Plates
  • Wear Strips
  • Bushings
  • Slide Assemblies
  • Guide Components

graphite plugged bronze bushings

Self Lubricating Graphite Plugged Bronze Sleeve Bushing
Plug Graphite Sleeve Bushing


  • Inch Sized Bushings
  • Metric Sized Bushings




Material


C83600 Bronze graphite bushings CuSn5Pb5Zn5 material

Similar or Equivalent Specification


CDA

ASTM

Asarcon

SAE

AMS

Federal

Military

Other

C83600

B505
B505M
B62
B145-4A

55

40
J461
J462

4855

QQ-C-390, B5;
QQ-B-1005, COMP 2

MIL-B-11553 COMP 2;
MIL-C-14345, ALLOY 1

Ounce
Metal




Chemical Composition



Cu%1

Pb%

Sn%

Zn%

Fe%

P%2

Ni%3

Al%

S%

Sb%

Si%

84.00-
86.00

4.00-
6.00

4.00-
6.00

4.00-
6.00


0.30


0.05


1.00


0.005


0.08


0.25


0.005



graphite plugged bronze bushingsBronze sleeve bearings flanged bronze bushings for sale


Performance


Graphite Plugged Cast Bronze Bushings can be utilized where heavy loads must be supported at low to medium speeds

The Plug Graphite Cast Bronze Bushing is able to withstand high temperatures up to 570 F
The self-lubricating feature allows bearings to be used where oiling is difficult, expensive to implement, and where grease/oil cannot be used. Excellent lubrication is achieved even under high loads at low speeds.
Self lubrication with specially embedded solid lubricants reduces friction. Coefficient of Friction: 0.04 to 0.2



Applications


Industrial couplings, handles for dental equipment, air actuators, pressure blocks for steel industry, bearing segments for steel industry, valve bodies, valves, bushings, pump parts, valves, transducer housings, valve bodies for the water meter industry, valves for the water meter industry, rings, printing presses, furnaces, pumps, low pressure valves, small gears, bearings, pump fixtures, impellers, valve bodies, pumps
