Sliding Bearing Slide Paths Pas Strips Material For Port And Terminal Cranes Bushes

Detail Information

Product Description

Detail Information

Features:

Low-maintenance, Lubricated Applications

Meterial:

Steel + Porous Bronze + Strips

Plating:

Tin Or Copper

Type:

Wrapped Bushes, Flanged Bearing, Thrust Washer

Finishing:

Tin Plated, Brass Plated

Special Use::

High-strength Steel Plate

Application:

Printing And Dyeing Machines, And Machines Used In The Ocean Industry, Etc.

Bearing Bushing Factory Price:

Tiffany@viiplus.com

Self-lubricating Bearing Bushing Manufacturer:

Https://www.viiplus.com/

High Light::

Self Lubricating Bronze Bushings, Dry Bearing

Dry Slide Bushings Bearing:

The Dry Slide Bushings Trademark Identifies A Whole Range Of Self-lubricated Dry Sliding Bushings And Bearings.

Bush Bearings Manufacturers Suppliers Exporters:

Plain Bearings. Long, Maintenance-free Service, Manufactures Bushings In Various Designs And From Different Materials. Tiffany@viiplus.com, Bushings - Configure And Purchase - Https://www.viiplus.com/

Highlight:

Bronze Bushing

Product Description

Dry Sliding Bearings | Coiled Steel Backing Bushing

Plain Bearings,Sleeve bearings,Flanged sleeve bearings & Thrust bearings made to order from china.For Shaft Diameter,Length,Dynamic Radial Load Capacity,ID,For Housing ID,OD,Maximum Temperature,Find a sleeve bushings.

VIIPLUS plain bearings is the complete source for your Sleeve Bushing & Self -Lubricating Bearings products. Order online for stock size and custom sizes.With no moving parts, plain bearings are the simplest type of bearing. Compared to ball and roller bearings, they generally handle higher temperatures and perform better in dirty environments.

Port and terminal cranes sleeve bushing for high winds, UV rays, saltwater and extreme temperatures

VSB-10 Strips, Slide paths PAS

Steel + Bronze Powder + /FibreStrips

for all the global industry

Provide high-quality self-lubricating products

Wrapped Steel Self Lubricating Bearings Oilless Sliding Series

Characteristics

VSB-10 Streifen, Gleitbahnen PAS

Strips PAS are available as an even material section. This material section can be used to make sliding elements in a variety
of shapes.

Characteristics of VSB-10 strips material

Very low stick-slip tendency
Low wear
Good chemical resistance
Low friction value
No tendency to weld to metal
Extremely swell-resistant
Does not absorb water

Preferred areas of application

Maintenance-free operation under dry-running conditions
Rotating or oscillating movements
Up to a velocity of 2 m/s
Linear movements
Temperature range -200 °C to 280 °C

Material composition

Strips Material composition

Layer system 10 srtips

1. Running-in layer

matrix with bulking agent¹
Layer thickness [mm]:	max. 0.03

2. Sliding layer

Tin-lead-bronze
Layer thickness [mm]:	0.20–0.35
Pore volume [%]:	approx. 30

3. Bearing back

Steel
Steel thickness [mm]:	Variable
Steel hardness [HB]:	100–180

1 The pores of the sliding layer are also filled with this lubricant mass.

Models and tables of dimensions

with steel back, maintenance-free

If these material sections are used to create slide paths, they have the following main functions:

Absorbing and transferring forces acting vertically to the running surface
Fixing moving components to each other
Ensuring guidance accuracy for axial movements over the entire service life

Strips are available in two material groups:

Material group P1 for maintenance-free, dry-running applications
Material group P2 for low-maintenance, lubricated applications

For the advantages of each group and help deciding which material group is best for the relevant use, please refer to the information provided in the section cylindrical bushes, flange liners and thrust washers.

VSB-10 Steel + Bronze Powder + /Fibre Bushings

· Bushing material suitable for lubricated applications
· self-lubricating bushings offer very good wear and low friction performance over a wide range of loads, speeds and temperatures in dry running conditions
· Anti-friction bearing suitable for linear, oscillating and rotating movements

Material is designed to operate without supplemental lubrication and will perform excellent when lubrication is present. Low friction, low wear rate, good sliding characteristics and very low absorption are a few of the features of this material. VSB-10 bushings will support rotary, linear and oscillating motion.

Strusture

1. /Fibre mixture thickness 0.01~0.03mm. It is the contact surface for the rotating shaft. Minute partides of the layer and the sintered bronze material combine to create a solid lubricant film, which coats the shaft.

2. Sintered bronze powder thickness 0.20*0.35mm,A special composition of powdered copper is thermally fused to the steel backing. This contact layer acts as an anchor for the layer and conducts the thermal build up away from the bearing surfaces.

3. Low-carbon steel backing. Setting the foundation of the bushings, the steel back provides exceptional stability, load carrying and heat dissipation characteristics.

Technical Data

Structure And Composition

· Metal-Polymer Composite Self-lubricating Bushing Material
· Steel Back + Porous Bronze Sinter +
· + Lead

Microsection

Sliding layer
+ Lead

Porous Bronze Sinter
Steel Backing

OPERATING PERFORMANCE
Dry	Very Good
Oil lubricated	Good
Grease lubricated	Fair
Water lubricated	Fair
Process fluid lubricated	Fai

Bearing Properties

GENERAL		Unit	Value
Maximum load, p	Static Dynamic	N/mm² N/mm²	250 140
Operating temperature	Min Max	°C °C	- 195 280
Coefficient of linear thermal expansion	Parallel to the surface	10^-6/K	11
Coefficient of linear thermal expansion	Normal to the surface	10^-6/K	30

DRY
Maximum sliding speed, U	m/s	2.0
Coefficient of friction		0.03 - 0.20 *

OIL LUBRICATED
Maximum sliding speed, U		m/s	＞2.0

* Depending on operating conditions

Technical data

Max. load	Static	250N/mm²
	Dynamic	140N/mm²
Max. speed	Dry	2m/s
	Lubrication	>2m/s
Max. PV (Dry)	Short-time	3.6N/mm^2*·m/s
	Continuous	1.8N/mm^2*·m/s
Temp.		-195℃~+280℃
Friction coefficient		0.03~0.20
Thermal conductivity		42W (m·k)^-1
Coefficient of thermal expansion		11*10^-6k^-1

Availability

Bearing forms available in standard dimensions

· Cylindrical bushes
· Flanged bushes
· Thrust washers
· Flanged washers
· Sliding plates

Metric bearings and imperial bushings made to order: standard bushing forms in special dimensions, half-bushings, special shapes obtained by stamping or deep drawing, customized bushing designs

Typical Applications

This material meets the demanding criteria for long life and maintenance free performance with or without lubrication.

Automotive: tractors, combines, crop sprayers, earth-movers, graders and other construction, auto machines, specific uses in power steering cylinders, steering gear thrust washers, disc brakes, calipers and pistons, shock absorbers, governor linkage, windshield wiper motor, tilt gear assemblies...
Business machines: photocopy machines, typewriters, mail sorters, postage meter systems, computer terminal printers and peripheral equipment, automatic printing devices, mail processing machinery...
Hydraulics and valves: pumps including gear, rotary, water, axial piston, and other types, ball, butterfly, poppet steam, and other valves and valve trunnions...
Home appliances: tape recorders, refrigerators, air conditioners, cleaners, polishers, sewing machines, ovens, dishwashers, clothes washing machines...And materials handling, marine engine, packaging, textile equipment, tools...etc.
