| Brand Name: | CHINA CUSTOM THERMOPLASTIC BUSHING SELF-LUBRICATING BEARINGS |
| Model Number: | CUSTOM THERMOPLASTIC AND TEX FABRIC WEAVE / GLASS FIBERS STAINLESS-STEEL 316 BEARINGS |
| MOQ: | >=500 Pieces |
| Price: | Negotiable |
| Payment Terms: | TT IN ADVANCE |
| Supply Ability: | Stainless Steel Bushing Manufacturers Self Lubricating Plain Bearings Suppliers |
Stainless steel bronze butterfly valve bushes are precision-engineered components designed specifically for use in butterfly valves. These bushings play a crucial role in ensuring the smooth and reliable operation of the valve, as they provide a wear-resistant interface between the rotating disc and the valve body.
Constructed from a combination of stainless steel and bronze, these bushes offer exceptional corrosion resistance and durability. Stainless steel is known for its high strength and ability to withstand harsh environmental conditions, while bronze provides excellent wear resistance and friction-reducing properties.
Valve repair and replacement often involve replacing worn or damaged bushings to restore the valve's performance. The stainless steel bronze butterfly valve bushes are designed to fit precisely into the valve's housing, ensuring a tight and secure fit. This not only improves the valve's sealing capabilities but also reduces the risk of leakage or malfunction.
These bushes are available in various sizes and configurations to suit different butterfly valve models and applications. Whether you need to repair a leaking valve or replace worn-out bushings, stainless steel bronze butterfly valve bushes are a reliable and cost-effective solution.
By using these precision-engineered stainless steel bronze bushings, you can ensure the smooth and efficient operation of your butterfly valves, reducing downtime and maintenance costs.
TORQUE ROD BUSH ASSEMBLY – STRADDLE MOUNT Valve Bush Woven Fabric Stainless Steel 316 Bushes Economical rolled fiber bearing for lighter load applications
High load capacity
Tolerance to bias is good
Excellent shock resistance
Good friction and abrasion
Good resistance to chemical corrosion
Plastic Bearing VIIPLUS Technologies PLASTIC BEARINGS MANUFACTURERS FOR Oil & Gas INDUSTRY
Bush-Red (Heavy Duty Bush)
Oil-free self-lubricating bearing is the absence of oil is no need to refuel or less refueling, our goal is to ensure that the bearings in this condition can also show good performance, and extend its service life as much as possible. It works in the initial stage of operation, the bearing surface of the solid lubricant due to the friction between each other to form a transfer film and cover the workpiece, the final formation of solid lubricating film to achieve the purpose of self-lubricating, it cut off the workpiece Between the direct contact, thus a good protection of the wear parts to extend the life of the bearing and the workpiece. Therefore, this kind of bearing in our lives are used in a variety of, it is used in special circumstances need additional fuel supply device, can reduce bearing operating costs, reduce equipment downtime maintenance, but also to mechanical maintenance more convenient. So now it is in the light industrial machinery, heavy machinery, construction machinery and other fields used in a lot of performance in our lives is perfect.
TEX Bushing,Customized Bushing , Fiber Bush
Plain Bearings and Sleeve Bearings Self-Lubricating Bearings, Liner Type Non-Metallic woven Stainless Steel 316 with fabric
Stainless steel 316 and steel-base polytetrafluoroethylene aramid fiber braid bearings are self-lubricating materials with wear-resistant fibers as the main surface material.The product has low friction coefficient, good bearing capacity, abrasion resistance and self-lubrication performance, mainly used in various high-grade valves and go-kart.
VSB-36 Bushing slide bearing bushings, oilless plain bearing
Stainless Steel316+/FABRIC
Apply to the oil or fuel work harder parts,wear resistance,low coefficient of ftiction,long life:good overall performance.Apply to the oil or fuel work harder parts,wear resistance,low coefficient of friction,long life;good iverall perfotmance.
VSB-36 Bushing
Stainless Steel316+/FABRIC
is of oil resistant, acid resistant, alkali resistant and seawater resistant, more over, there is no lead in the surface layer and so is particularly fit for application in food machinery, alkali flow meters, pumps motion elements in pharmaceutical machines, printing machines chemical engineering machines and other ocean industry. The bushing is a triple layers composites one, the base material is stainless steel back and a film of heat resistant power filled being calendered onto the sintered spherical bronze interlayer.
Max. load | Static | 350N/mm2 |
Dynamic | 180N/mm2 | |
Max. speed | Dry | 0.5m/s |
Lubrication | >1m/s | |
Max. PV (Dry) | Short-time | 3.6N/mm2*·m/s |
Continuous | 1.8N/mm2*·m/s | |
Temp. | -50℃~+250℃ | |
Friction coefficient | 0.03~0.20 | |
Thermal conductivity | 42W (m·k)-1 | |
Coefficient of thermal expansion | 11*10-6k-1 | |
Bearing forms available in standard dimensions
· Cylindrical bushes
· Flanged bushes
· Sliding plates
· Thrust washers
· Flanged washers
VIIPLUS bearing is a leading self-lubricating bearing manufacturer and supplier in China. We are highly proficient in the production of various self-lubricating bearings, bushes, and the sliding blocks, etc. Our main product catalogue now includes the oilless self-lubricating bearing, composite bearing, copper bearing, wrapped bronze bearing, bimetallic bearing, thermoplastic bushes, and more. All our products are characterized by reliable performance and low price. They are very popular and widely applicable in different industries including the automobile, machine tools, moulds, metallurgical machinery, mining machinery, textile machinery, hoisting machinery, construction machinery, printing machines, irrigation machinery, injection molding machines, food machinery, ports, marine machinery, and the agricultural and forestry machinery, etc.
Low friction woven fabric oilless bearing VSB-36 TEX is widely used in high temperature production lines, construction machinery, automobile chassis parts, ball valves, butterfly valves, pumps and chemical industries and high-speed trains and other heavy low and cannot refuel occasion etc.
