China Bronze Gleitlager manufacturer

Centrifugal Casting Bronze C86200 / C86300 Bushings Self Lubricant Bush Customized Size

Product Details:
Place of Origin: Self Lubricating Bearings Manufacturers
Brand Name: REPLACE BRAND GARLOCK BEARINGS (GGB)
Certification: DIN 1494, ISO 3547 STANDARD BUSHING
Model Number: BUSHING TYPE FLANGED PLAIN SLEEVE
Payment & Shipping Terms:
Minimum Order Quantity: NEGOTIABLE
Price: Competitively Priced vs DU DX, Provides Lubricating Bush
Packaging Details: WOOD PALLET ,WOODEN CASES,CARTON,BUSHINGS EXPORT STANDARD, CUSTOMER SPECIFIED REQUIREMENTS
Delivery Time: 7-20 DAYS,STOCK SIZE BUSHING IMMEDIATE DELIVERY
Payment Terms: TT IN ADVANCE WESTERN UNION
Supply Ability: Flanged Bronze Bushings, Bronze Thrust Washers, Self Lubricating Bronze Bushings
Contact Now

Detail Information

Material: Self Lubricaing Bearings Port: Shanghai
Characteristic: Low-maintenance And Maintenance-free Plain Bearings Type: Bushes, Collar Bushes, Washers, Strips Or Special Designs
Size: Standard Size Available Quality: High Quality
High Light:

sintered self lubricating bushes

,

self lubricating bronze bushings

Product Description

Centrifugal Casting Bronze C86300 Bushings Diameters Concentric Tolerances Dimensions



Bronze bushings internal spiral "double loop" with oil groove



Our graphite bronze bushing can provide customers with a complete mechanical lubrication system. Our graphite is oil-less, self-lubricating, and designed for long life. This insures less down time and eliminates problems caused by high and low temperatures.ALL SHARP EDGES ARE TO BE REMOVED.



Material
CuZn25Al5Mn4Fe3
Typical Application
consecutive casting and rolling machines, mine-exploiting equipments, ships, steam engine, etc.
Density g/cm3
8
Hardness HB
>210
Tensile Strength N/mm²
>750
Yeild strength N/mm²
>340
Elongation %
>12
Coefficient of linear expansion 10-5/℃
2.2
Heat-conducting Coefficient W(/m.k)
38~55
Flexibility Coefficient KN/mm²
100~140
Temp. Limits ℃
-40~+200
Max. Dynamic Load N/mm²
98
Max.speed m/s
Dry Lubrication 0.3; Oil Lubrication 1.0
Max.PV N/mm²*m/s
Dry Lubrication 1.65; Oil Lubrication 3.25
Friction
Dry Lubrication 0.12~0.16; Oil Lubrication 0.03~0.08



Plain Bearings & Self-lubricating Bushings | viiplus Surface Engineering| Metal-Polymer Bearings



Rolled Standard Profile

Cylindrical Sliding Bearings

Flanged Bushings

Thrust Washers

Strip Sections



Engineering Machinery The various sliding bearings of VIIPLUS BEARINGS are widely used in the chassis system, body system and hydraulic system of construction machinery and construction machinery. Jf-mp friction welding sleeve is used for supporting wheel, sprocket, guide wheel; The double metal and SF series bushing are used in the arm frame, connecting rod and leg of pump truck. JDB series solid inlay lubrication series are used in movable arm, bucket rod, amplitude modulation mechanism, oil cylinder etc.



Self Lubricating Plain Bearing

With the increasing number of types of bearings



Now the advantage of self-lubricating bearings is obvious The advantages of sliding bearings are obvious

With the increasing number of types of bearings,The application of bearings in our lives will also be more extensive, I believe that the future development of bearings will be better!



Application area



viiplus self lubricatingbearing products are widely used in all industrial fields

Widely used in hydraulic and pneumatic industries, forging machine tool industry, plastics machinery industry, lifting and handling machinery, port machinery, office, fitness machinery, textile machinery, food packaging, filling machinery, chemical machinery, printing and packaging, paper making machinery, automobiles, railways Steam locomotives, shipbuilding industries, presses, metallurgical machinery, construction machinery, etc.



viiplus is a professional bearing manufacturer,
Our goal is to continuously contribute to society through technological innovation



VIIPLUS Bearing Co., Ltd.is one of the entities in China that specializes in the production of self-lubricating bearings, plain bearings, composite bearings, oil-free bearings, dry bearings, and maintenance-free bearings. Its product quality and performance have reached the level of foreign peer companies.





Sales network



From the perspective of quality components, equipment capabilities, material quality, process requirements, and environmental conditions must ultimately be achieved by the operator through actual operations.

Self Lubricating Plain Bearing



Viiplus Sliding Bearings



Rolled dry sliding bearings (PTFE)
Rolled dry sliding bearings (POM)
Rolled sliding bearings (CuSn8)
Solid lubricant sliding bearings
Rotated solid sliding bearings
Bimetal sliding bearings
Rolled sliding bearings with solid lubricant
Special automotive parts
Sintered bronze and sintered iron Sliding bearings
Plastic sliding bearings
Gleitlager
