| Brand Name: | VIIPLUS |
| Model Number: | DEEP GROOVE BALL BEARING |
| MOQ: | NEGOTIABLE |
| Price: | Price Graphite Wear Plate Parts Factory Price |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | Bronze Bushings Online • Sliding Bearings Manufacturers • Self-lubricating Bushing Suppliers |
ABEC-5 Compressors Axial Angular Contact Ball Bearings, supplied by China, feature high quality and reliability. These bearings are designed for use in compressors, ensuring smooth and efficient operation under various conditions. The axial angular contact design provides superior load-bearing capacity and durability, making them suitable for demanding applications. Additionally, the high-quality materials and precision manufacturing ensure long-lasting performance and reliability.
Angular contact ball bearings have inner and outer ring raceways that are displaced relative to each other in the direction of the bearing axis. This means that these bearings are designed to accommodate combined loads, i.e. simultaneously acting radial and axial loads.
The axial load carrying capacity of angular contact ball bearings increases as the contact angle increases. The contact angle is defined as the angle between the line joining the points of contact of the ball and the raceways in the radial plane, along which the combined load is transmitted from one raceway to another, and a line perpendicular to the bearing axis .
Here are examples of applications in which angular contact ball bearings might be used:
Industrial pumps
Industrial gearboxes
Renewable energy
Compressors
Industrial electric motors & generators
Trucks, trailers and buses
Metals
viiplus can supply both standard and precision angular contact ball bearing.
Single Row Angular Contact Ball Bearing
Double Row Angular Contact Ball Bearing
Four Point Contact Ball Bearing
Pressed steel, Pressed brass, Polyamide, Hard fabrics, Machined solid brass
C = 15˚ ; AC = 25˚ ; B= 40˚ contact angle
SAE52100 Steel and Si3N4 ceramic ( suffix HQ1 )
ABEC-5, P5 = ISO Class 5 Tolerance
ABEC-7, P4 = ISO Class 4 Tolerance
ABEC-9, P2 = ISO Class 3 Tolerance
|
Model
|
Old Model
|
Dimesion(mm)
|
Weight
|
||
|
|
|
d
|
D
|
T
|
|
|
7000AC
|
46100
|
10
|
26
|
8
|
0.02
|
|
7001AC
|
46101
|
12
|
28
|
8
|
0.02
|
|
7002AC
|
46102
|
15
|
32
|
8
|
0.03
|
|
7003AC
|
46103
|
17
|
35
|
10
|
0.03
|
|
7004AC
|
46104
|
20
|
42
|
10
|
0.07
|
|
7005AC
|
46105
|
25
|
47
|
12
|
0.08
|
|
7006AC
|
46106
|
30
|
55
|
13
|
0.12
|
|
7007AC
|
46107
|
35
|
62
|
14
|
0.14
|
|
7008AC
|
46108
|
40
|
68
|
15
|
0.21
|
|
7016ACM
|
46116H
|
80
|
125
|
22
|
0.9
|
|
7017AC
|
46117
|
85
|
130
|
22
|
0.95
|
|
7017ACM
|
46117H
|
85
|
130
|
22
|
0.95
|
|
7018AC
|
46118
|
90
|
140
|
24
|
0.96
|
|
7018ACM
|
46118H
|
90
|
140
|
24
|
0.96
|
|
7019AC
|
46119
|
95
|
145
|
24
|
1.2
|
|
7019ACM
|
46119H
|
95
|
145
|
24
|
1.2
|
|
7020AC
|
46120
|
100
|
150
|
24
|
1.25
|
|
7020ACM
|
46120H
|
100
|
150
|
24
|
1.25
|
|
7021ACM
|
46121H
|
105
|
160
|
26
|
1.61
|
|
7022ACM
|
46122H
|
110
|
170
|
28
|
2.44
|
|
7024ACM
|
46124H
|
120
|
180
|
28
|
2.62
|
|
7026ACM
|
46126H
|
130
|
200
|
33
|
3.912
|
|
7028ACM
|
46128H
|
140
|
210
|
33
|
4.2
|
|
7030ACM
|
46130H
|
150
|
225
|
35
|
5
|
|
7032ACM
|
46132H
|
160
|
240
|
38
|
5.02
|
|
7034ACM
|
46134H
|
170
|
260
|
42
|
8.3
|
|
7038ACM
|
46138H
|
190
|
290
|
46
|
11.2
|
|
7040ACM
|
46140H
|
200
|
310
|
51
|
14.3
|
|
7044ACM
|
46144H
|
220
|
340
|
56
|
18.5
|
|
7217ACM
|
46217H
|
85
|
150
|
28
|
1.88
|
|
7222ACM
|
46222H
|
110
|
200
|
38
|
4.81
|
|
7224ACM
|
46224H
|
120
|
215
|
40
|
5.6
|
|
7226ACM
|
46226H
|
130
|
230
|
40
|
7.3
|
|
7228ACM
|
46228H
|
140
|
250
|
42
|
7.76
|
|
7302AC
|
46302
|
15
|
42
|
13
|
0.094
|
|
7303AC
|
46303
|
17
|
47
|
14
|
0.12
|
|
7304AC
|
46304
|
20
|
52
|
15
|
0.146
|
|
7305AC
|
46305
|
25
|
62
|
17
|
0.23
|
|
7306AC
|
46306
|
30
|
72
|
19
|
0.35
|
|
7307AC
|
46307
|
35
|
80
|
21
|
0.47
|
|
7307ACM
|
46307H
|
35
|
80
|
21
|
0.47
|
|
7308AC
|
46308
|
40
|
90
|
23
|
0.69
|
|
7308ACM
|
46308H
|
40
|
90
|
23
|
0.69
|
|
7309AC
|
46309
|
45
|
100
|
25
|
0.89
|
|
7309ACM
|
46309H
|
45
|
100
|
25
|
0.89
|
