Flanged Bronze Metallic Self-Lubricating Bushings with thru Holes Material CuSn8 / CuSn6.5

Place of Origin Self Lubricating Bearings Manufacturers
Brand Name REPLACE BRAND GARLOCK BEARINGS (GGB)
Certification DIN 1494, ISO 3547 STANDARD BUSHING
Model Number BUSHING TYPE FLANGED PLAIN SLEEVE
Minimum Order Quantity NEGOTIABLE
Price Competitively Priced vs DU DX, Provides Lubricating Bush
Packaging Details WOOD PALLET ,WOODEN CASES,CARTON,BUSHINGS EXPORT STANDARD, CUSTOMER SPECIFIED REQUIREMENTS
Delivery Time 7-20 DAYS,STOCK SIZE BUSHING IMMEDIATE DELIVERY
Payment Terms TT IN ADVANCE WESTERN UNION
Supply Ability Flanged Bronze Bushings, Bronze Thrust Washers, Self Lubricating Bronze Bushings

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Meterial Bronze CuSn8 092 Plating Tin Or Copper
Type Sleeve Port Shanghai
Quality High Bearing Bushing Factory Price Tiffany@viiplus.com
Self-lubricating Bearing Bushing Manufacturer Https://www.viiplus.com/ High Light PTFE Coated Self Lubricating Plain Bearing, Teflon Self Lubricating Plain Bearing, Steel Backed Self Lubricating Plain Bearing
Characteristic Втулки скольжения (биметаллические подшипники скольжения) Dry Slide Bearing Self Lubricating Plain Bearing Work In High Temp & Submerged Applications Where Grease, Oil & Plastics Fail. Reduced Costs & Downtime. Non-galling. Increased Reliability. Run Dry & Keeps Running.
Bush Bearings Manufacturers Suppliers Exporters Plain Bearings. Long, Maintenance-free Service, Manufactures Bushings In Various Designs And From Different Materials. Tiffany@viiplus.com, Bushings - Configure And Purchase - Https://www.viiplus.com/
High Light

self lubricating bearing

,

sintered self lubricating bushes

Leave a Message
Product Description

Metallic Self-Lubricating (Lubrication Free) Bushings material a cold formable homogenous bronze (CuSn8).


Bronze Wrapped Bushings 092 Series bushing material is provided with a uniform pattern of indents which act as grease reservoirs.Wrapped Bronze with thru holes Series

These through holes serve as lubricant reservoirs to rapidly build up a lubrication film in the startup movement and subsequently reduce the startup friction.


 Plain Bearings and Sleeve Bearings Metric Bronze CYLINDRICAL FLANGE BUSHES CuSn8 with Lubrication 092 boccole |VSB-22

ROLLED SLIDING BEARINGS (CUSN8)
VSB-22 FLANGE BUSHES Bronze Bearings made of CuSn8 with Lubrication Indents
Bronze Wrapped Bearing with Oil Pockets(092 CYLINDRICAL BUSHES)





VSB-22 092 CYLINDRICAL BUSHES FLANGE BUSHES
· Bearing material made of solid bronze strip with indents for lubrication
· Good wear resistance, suitable for rough conditions
· Optimum performance under relatively high loads and low speeds

· 1.Easy for fitting and lubricating
· 2.High load capacity
· 3.Inner Diameter machineable parts are available against order
· 4.High level thermal conductivity
· 5.Minimum overall dimensions
· 6.Chemical resistance.

· Initial pre-lubrication at assembly required...


Strusture




The bearings are wrapped from a cold formed homogenous bronze (CuSn8) with exceptional material properties. The standard sizes are fitted with diamond shaped lubrication indents in the bearing surface. These indents serve as lubricant reservoirs to rapidly build up a lubrication film at the start of movement and thereafter reduce the running friction. The material is suitable for construction and agricultural machinery applications.



Technical Data




Structure And Composition

Bronze Bearings and Bronze Sleeve Bushings made of CuSn8 with Lubrication Indents



Microsection

Flanged Bronze Metallic Self-Lubricating Bushings with thru Holes Material CuSn8 / CuSn6.5 0

CuSn8 with
composition
Sn 8 %
P < 0.05 %
Cu Rest




OPERATING PERFORMANCE

Dry

Poor

Oil lubricated

Good

Grease lubricated

Good

Water lubricated

Poor

Process fluid lubricated

Poor



Bearing Properties



GENERAL



Unit

Value

Maximum load, p

Static
Dynamic

N/mm2
N/mm2

120
40

Operating temperature



°C

- 100~200











GREASE LUBRICATED







Maximum sliding speed,



m/s

2.0









Coefficient of friction





0.08 - 0.25



RECOMMENDATIONS















Surface hardness

Normal

HB
110-150







Tech. Data



Max.Load

Static

120N/mm²

Elongation

40%



Dynamic

40N/mm²



Temp

-100℃~+200℃





Coefficient of friction

0.08~0.25





Max.speed(Lubrication)

Max.Speed

2m/s

Thermal conductivity

58W(m*k)-1





Max.PV

Max.PV

2.8N/mm²*m/s

Coef. of thermal expansion

18.5*10-6K-1





Tensile strength

Tensile strength

450N/mm²









Hardness

Hardness

HB 100-150







Availability


Bearing forms available in standard dimensions
· Cylindrical bushes
Bearing forms made to order: cylindrical bushes with non-standard dimensions, flanged bushes, sliding plates, customized bearing designs



Typical Applications


This type of bushing is widely applied in hoisting machines and other construction machines, automobiles, tractors, trucks, machines tools and some mineral engines. It can be fabricated into bushes, half bearings, flanged bushes, taist washers, spherical bearing andsoon.
