Glacier Garlock Bearings PTFE Slide Bearing Plates & Strips Composite Cylindrical Bushings

Place of Origin Plain Bearing Material
Brand Name VIIPLUS strips material
Certification DIN 1494, ISO 3547
Model Number composite bearing strips plain bearings
Minimum Order Quantity negotiable
Price Steel + sintered bronze + PTFE flat strip material inch sizes Manufacturers,Factory Price
Packaging Details EXPORT CARTON WOOD PALLET WOODEN CASE
Delivery Time 2-3 Weeks
Payment Terms T/T
Supply Ability 1200000 Piece/Pieces per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Bushing Strips Carbon Steel +Bronze+PTFE +Strips Three Layer Composite Bearing High Strength, Anti - Fatigue, Anti - Impact
Bearings Slide Plates- PTFE Slide Bearing Plates Application Composite Bearings Cylindrical Bushings
Item MULTILAYER MATERIAL (TYPE "DU") FOR SLIDING PLATES Form Multilayer Material Type DU In Plate Form
Bearing Bushing Factory Price Tiffany@viiplus.com Self-lubricating Bearing Bushing Manufacturer Https://www.viiplus.com/
Bush Bearings Manufacturers Suppliers Exporters Plain Bearings. Long, Maintenance-free Service, Manufactures Bushings In Various Designs And From Different Materials. Tiffany@viiplus.com, Bushings - Configure And Purchase - Https://www.viiplus.com/
High Light

du strip

,

plain sleeve bearing strips

Leave a Message
Product Description

PTFE Slide Bearing Plates & Strips Composite Bearings, Multilayer material type DU in plate form.

PTFE Composite -PTFE •tin bronze copper layer sheet steel backing copper layer • tin layer

VIIPLUS CHINA offers the self-lubricating bearings steel material strips Slide Plates- PTFE Slide Bearing Plates that can be used for bearing bush.

Similar material to DU from GGB (Glacier Garlock Bearings). Steel + sintered bronze + PTFE and additives.
Maximum Static Load: 250 N/mm2
Maximum Dynamic Load: 140 N/mm2
Range Operating Temperature: - 200 °C / + 280 °C
Sliding Speed Max.: 2,5 m/s

01. Steel + sintered bronze+ PTFE
Consisting of a metal backing for high mechanical strength and a sintered bronze layer, Metal-Polymer bearings are impregnated with an anti-friction overlay

02. Steel + sintered bronze+ POM
Metal/polymer composite plain bearings are bearings for very small radial or axial design envelopes. They run with little noise and are.

03. Metal-Polymer Anti-Friction Plain Bearings
Metal/Polymer Composite Plain Bearings: Advantages. High static loads possible, relatively good heat dissipation,Low coefficient of friction (PTFE)

Bearing Sleeve Bush Material & Strips Get A quote.



Bearing Bush is also known as bearing sleeve or adapter sleeve. It is widely used in the light industry and is installed for fixing the rotated bearing.
We manufacture strips & plate of bearing bush. Cylindrical bushings (DIN 1494) Self-Lubricating Flat Strips - Metric Sizes Inch Sizes & Customize Length with different thicknesses.Three-layer composite bearing Flat Strips Factory in China, China Sleeve Bushing material Supplier, flat strip plate Wholesale from China | Sliding Bearings material made to order from china



self lubricating bronze bushing Multilayer material type DU in plate form.



Flat Strips Plate Sleeve Bushing Material


The VIIPLUS range of self-lubricated dry sliding bearings. A composite structure, SF-1 SIMILAR DU flat strips consists of a carbon steel backing, an intermediate layer of sintered bronze, PTFE based sliding lining. From a technical point of view, the product is already widely known and new applications are constantly being identified to take advantage of the high load capacity, the self-lubricated feature and the excellent ratio between cost and performance of the whole range.



Self-Lubricating Flat Strips - Inch Sizes



Self-Lubricating Flat Strips - Inch Sizes catalog including P/N ,Width,High,Length Self-Lubricating Flat Strips - mm Sizes made to order from china.



Strips Area of Use



A dry running bearing with a low coefficient of friction, good wear properties and sliding characteristics. It can be used in both rotary and oscillating applications



Strips Feature



Flat Strips Plain Bearing It is made of high quality low-carbon steel, and sintered and rolled copper alloy as its surface. It has high fatigue strength, load capacity and impact strength.



Strips Structure


Steel bronze powder with PTFE/Fibres mixture


1. PTFE fibres mixture 0.01-0.03mm, lead free: provides an excellent initial transfer film, which effectively coats the mating surface of the bearing assembly, forming an oxide type solid lubricant film.

2. Sintered bronze powder 0.20-0.35mm: provides maximum thermal conductivity away from the bearing surface, also serves Dryslide structural detailas a reservoir for the PTFE-lead mixture.

3. Low-Carbon Steel: provides exceptionally high load carrying capacity.

4. Tin plating 0.002mm: provides good corrosion resistance

Self-Lubricating Multilayer Composite Bushing Life

1).PV Value
PV value is an effective criterion to calculate the service life of sliding bearing. If there is need to prolong the service Life, PV value must be reduced.

2).Ambient Temperature
The higher the working temperature is, the shorter the life of the products would be.

3).Quality of the Mating Surface
Service life self-lubricating can be obviously prolonged if its mating axis is made by alloy steel or is plated by hard chrome and with surface Roughness Ra=0.4~0.63.



Typical Applications


Can meet the demanding criteria for long life and trouble-free performance with or without lubrication.
Automotive: tractors, combines, crop sprayers, earthmovers, and road graders. Specific uses in power steering cylinders, steering gear thrust washers, disc brakes, callipers, pistons, shock absorbers, governor linkage, windshield wiper motor, and tilt gear assemblies…
Office Equipment: photocopy machines, mail sorters, postage meter systems, computer printers, peripheral equipment, automatic printing devices, and mail processing machinery…
